2010 Stumpjumper Expert
0 Commentaires
Semi Rigide de Compétition XC La tradition a parfois du bon. Les puristes du XC…
Coloris:
Gloss White/White
Quelle est ma taille ?
Sélectionnez un(e) Taille
Caractéristiques du produit
Semi Rigide de Compétition XC La tradition a parfois du bon. Les puristes du XC vont être servis: un cadre aluminium M5 ultra léger, des composants de choix pour un vélo explosif de nervosité et de maniabilité. Associez ces ingrédients à une géométrie légendaire et en perpétuelle évolution depuis 25 ans, vous obtiendrez l'arme de XC la plus utilisée dans le monde.
Sweet looking Stumpjumper HT frame with curved top tube is also sweet riding due to its M5 manipulated alloy construction
DT Swiss X420SL 24mm-wide rims are sleeved and eyeletted for a sturdy and lightweight package that makes the climb out effortless
Specialized Phenom saddle with hollow Cr-Mo rails is a lightweight and minimalist design, tuned for sit bone flex and comfortable climbing
Avid Elixir R lightweight hydraulic brakes with tool-free reach adjust and long lasting metallic pads halt bombing runs with superb control and modulation
Battle-tested RockShock SID Race 90mm air-sprung fork with rebound adjust, lockout and FloodGate control dials in the perfect pedaling platform while retaining light weight
9mm thru-axle front hub with hi/lo flanges and DT Swiss Competition spokes comes with 24/28mm end caps for increased tracking strength and multi-fork compatibility, with a quality DT Swiss alloy freehub in the rear
Spécifications techniques
FRAMESET
FRAME
M5 manipulated alloy frame, curved TT, SS w/ disc brake mount
HEADSET
Campy style cartridge bearings for integrated alloy HT
SEAT BINDER
7050 hard annodized alloy collar w/bolt, 34.9mm clamp ID
SUSPENSION
FORK
RockShox SID Race for Specialized, 90mm travel, air spring, rebound and floodgate compression adj.w/ LO, alloy steerer
WHEELS
FRONT TIRE
S-Works The Captain, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
REAR TIRE
S-Works Fast Trak LK, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
INNER TUBES
Ultralight presta valve
RIMS
Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
FRONT HUB
Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, oversized end caps, 9mm DT RWS, alloy QR, 28h
REAR HUB
Custom DT Swiss 330SL w/ alloy freehub, QR, 32h
SPOKES
DT Swiss Competition 1.8/1.6mm stainless
DRIVETRAIN
FRONT DERAILLEUR
Shimano M660 SLX, 34.9mm clamp, top swing, top pull
REAR DERAILLEUR
SRAM X-0, 9-speed mid cage
SHIFT LEVERS
SRAM X-9 aluminum trigger
CASSETTE
Shimano HG61, 9-speed, 11-34t
CHAIN
SRAM PC-971, 9-speed w/Power Link
CRANKSET
Custom Shimano FC-M762, 2pc., 15.5:170mm, others: 175mm
CHAINRINGS
44A x 32A x 22S, 4-bolt, 104/64mm
BOTTOM BRACKET
Custom Shimano, outboard bearing
COCKPIT
STEM
3D forged alloy, adjustable rise, 31.8mm clamp
HANDLEBARS
Specialized XC low rise bar, 7050 butted alloy, 31.8mm, 660mm wide, 8 degree back sweep, 6 degree up
GRIPS
Specialized waffle lock on grip (15.5/17.5) Specialized Thick lock on grip (others)
SADDLE
Specialized Phenom, hollow Cr-Mo rails, thin foam, 15.5/17.5: 130mm, others: 143mm
SEATPOST
2014 butted alloy, single bolt setback, 30.9mm
BRAKES
FRONT BRAKE
Custom Avid Elixir CR SL, alloy backed semi-met pads, 160mm rotor
REAR BRAKE
Custom Avid Elixir CR SL, alloy backed semi-met pads, 15.5/17.5: 140mm, others: 160mm rotor
BRAKE LEVERS
Custom Avid Elixir CR SL Hydraulic, tool-less adj. reach and pad contact
ACCESSORIES
PEDALS
None
*Poids basés sur les cadres peints en production comme illustré. Les poids réels varieront en fonction de la couleur, de la taille du cadre et de la variation des composants. Les spécifications sont sujettes à modification sans préavis.
Géométries
| 15.5 | 17.5 | 19 | 21 | |
|---|---|---|---|---|
| Ground-Top | 878mm | 896mm | 915mm | 934mm |
| Bottom Bracket Height - Low Setting | 304mm | 304mm | 304mm | 304mm |
| Longueur tube (horizontal) | 555mm | 590mm | 615mm | 640mm |
| Hauteur de la douille de direction | 120mm | 140mm | 160mm | 180mm |
| Head Tube Angle - Low Setting | 70.5° | 70.5° | 70.5° | 70.5° |
| Seat Tube Angle (Actual) - Low Setting | 73° | 73° | 73° | 73° |
| Top Tube Length (Actual) | 538mm | 567mm | 590mm | 614mm |
| Seat Tube Length - Center to Top | 394mm | 445mm | 483mm | 533mm |
| Empattement | 1034mm | 1070mm | 1096mm | 1122mm |
| Hauteur cadre à l’entrejambe | 741mm | 780mm | 811mm | 846mm |
| Stack | 574mm | 592mm | 611mm | 630mm |
| Reach | 380mm | 409mm | 428mm | 447mm |
| Longueur bases | 424mm | 424mm | 424mm | 424mm |
| Longueur manivelles | 170mm | 175mm | 175mm | 175mm |
| Largeur de cintre | 660mm | 660mm | 660mm | 660mm |
| Longueur de potence | 75mm | 90mm | 105mm | 105mm |
| Longueur de tige de selle | 350mm | 350mm | 400mm | 400mm |
Téléchargement manuel
Consultez les avertissements de sécurité dans la documentation disponible sur cette page dans la section « Téléchargements manuels ».
