Bicicleta Chisel Hardtail Comp
5
4 Avaliações
The all-new Chisel Comp is the perfect bike to begin your journey into XC riding…
Nós entregamos. Basta dizer quando e como.
Detalhes do Produto
The all-new Chisel Comp is the perfect bike to begin your journey into XC riding and racing, with all of the features to get you to that elusive ""top step"" at a price that leaves some jingle jangle left over for race entries.
This Chisel comes dressed with SRAM's crisp-shifting NX Eagle 1x12 drivetrain and powerful Level T hydraulic disc brakes, a 100mm (Size XS: 80mm) RockShox Judy Gold fork, and 25mm internal width alloy wheels wrapped in 2.35 Fast Track Control casing tires.
- We asked ourselves, “How do we bring pro-level performance down to a price more riders can afford?” D'Aluisio Smartweld Technology, that's how. Smartweld allows us to create the most consistent, high-strength welds possible while taking full advantage of compliant, hydroformed alloy tubes. The result? One of the lightest alloy hardtail frames out there at 1,350g, which also features size-tuned stiffness.
- The new Chisel also houses all of the modern features that you expect from an XC bike, like Progressive XC Geometry with a 68-degree headtube angle and longer reach, internal cable routing, a threaded bottom bracket, boost spacing, 30.9mm dropper post compatibility, and 1x-only drivetrains.
Especificações Técnicas
Quadro
QUADRO
Specialized D'Aluisio Smartweld M5 Alloy, Hydroformed tubes, Progressive XC Geometry, internal cable routing, BSA BB, 12x148mm spacing, 30.9mm Dropper post compatible
ABRAÇADEIRA DO CANOTE
Specialized Alloy, 34.9mm
Suspensão
GARFO
RockShox Judy Gold, Motion Control damper, Solo Air, 42mm offset, 15x110mm thru-axle, 100mm of travel (XS - 80mm travel)
Cockpit
SELIM
Body Geometry Power Sport, steel rails
MESA
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
MANOPLAS
Specialized Trail Grips
GUIDÃO
Specialized Alloy XC minirise, double-butted alloy, 8-degree backsweep, 6-degree upsweep, 10mm rise, 31.8mm
CANOTE DO SELIM (Enter Translation here)
Specialized Alloy, Single Bolt, 30.9mm
Freios
FREIO DIANTEIRO
SRAM Level T, hydraulic disc, 160mm/180mm Centerline Rotor
FREIO TRASEIRO
SRAM Level T, hydraulic disc, 160mm Centerline Rotor
Caixa de Direção
CÂMBIO TRASEIRO
SRAM NX Eagle, 12-speed
CASSETE
SRAM NX Eagle, 12-speed, 11-50t
TROCADORES
SRAM NX Eagle, trigger, 12-speed
CORRENTE
SRAM, SX Eagle, 12-speed
PEDIVELA
SRAM X1000 Eagle, DUB, 170/175mm 32T
COROAS
32T
MOVIMENTO CENTRAL
SRAM DUB, BSA 73mm, Threaded
Rodas & Pneus
AROS
Specialized Alloy, hookless, Tubeless ready, 25mm inner width
CUBO DIANTEIRO
Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h
CUBO TRASEIRO
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
PNEU DIANTEIRO
Specialized Fast Trak, Control Casing, T7 Compound, 29x2.35
PNEU TRASEIRO
Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35
RAIOS
Stainless, 14g
CÂMARAS
Standard, Presta valve
Peso
DÍNAMO
11.82kg (26 lb, .9 oz)
DÍNAMO
LG
* A informação sobre o peso tem como base um quadro pintado, conforme a imagem. Ele pode variar de acordo com a cor e tamanho do componente. As especificações estão sujeitas a alterações sem aviso prévio.
Geometria
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Comprimento do pedivela | 165mmm | 170mm | 175mm | 175mm | 175mm |
| Largura do guidão | 750mm | 750mm | 750mm | 750mm | 750mm |
| Comprimento da mesa | 60mm | 60mm | 70mm | 70mm | 70mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
| Comprimento do canote | 350mm | 350mm | 400mm | 400mm | 400mm |
| Comprimento da rabeira inferior | 432mm | 432mm | 432mm | 432mm | 432mm |
| Altura (Central ao topo da caixa) | 591mm | 605mm | 605mm | 619mm | 633mm |
| Alcance (medido do central ao ct da cx de direção) | 385mm | 405mm | 430mm | 455mm | 480mm |
| Distância entre eixos | 1070mm | 1099mm | 1124mm | 1154mm | 1185mm |
| Comprimento do tubo da caixa de direção | 95mm | 95mm | 95mm | 110mm | 125mm |
| Comprimento do tubo superior, Horizontal | 555mm | 578mm | 603mm | 632mm | 661mm |
| Bike Standover Height | 732mm | 762mm | 792mm | 816mm | 847mm |
| Ângulo do tubo da caixa de direção | 68° | 68° | 68° | 68° | 68° |
| BB Height | 304mm | 309mm | 309mm | 309mm | 309mm |
| Seat Tube Length | 367mm | 400mm | 430mm | 470mm | 520mm |
| BB Drop | 68mm | 63mm | 63mm | 63mm | 63mm |
| Ângulo do tubo do selim | 74° | 74° | 74° | 74° | 74° |
| Trail | 103mm | 103mm | 103mm | 103mm | 103mm |
| Fork Length, Full | 486mm | 506mm | 506mm | 506mm | 506mm |
| Curvatura do Garfo | 44mm | 44mm | 44mm | 44mm | 44mm |
| Central ao Eixo dianteiro | 647mm | 674mm | 699mm | 730mm | 760mm |
