Shiv Comp
0 Reviews
We ignored UCI rules and designed the Shiv exclusively for triathlon: with unmatched…
FRAME
Specialized Shiv 10r carbon, FACT IS construction, crosswind-optimised airfoils, 1-1/8" lower bearing, OSBB, Control Tower Fit System, Fuelselage Integrated Hydration System
FORK
Specialized FACT Aero carbon monocoque fork, carbon steerer and crown for 1-1/8" bearing
HANDLEBARS
Specialized hydroformed alloy aerobars
STEM
Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt, 31.8mm
HEADSET
1-1/8" upper and lower, Cr-Mo cartridge bearings
TAPE
Specialized S-Wrap, w/ gel
SADDLE
BodyGeometry Romin Evo Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Shiv Aero FACT carbon, 12.5mm
SEAT BINDER
Shiv Seat Clamp
FRONT WHEEL
DT Axis 2.0
REAR WHEEL
DT Axis 2.0
FRONT TYRE
Specialized Turbo Elite, 100TPI, aramid bead, BlackBelt protection, 700x23c
REAR TYRE
Specialized Turbo Elite, 100TPI, aramid bead, BlackBelt protection, 700x23c
INNER TUBES
Standard presta valve
SHIFT LEVERS
SRAM TT500 SL
FRONT DERAILLEUR
SRAM Apex
REAR DERAILLEUR
SRAM Rival
CASSETTE
SRAM PG-1050, 10-speed, 11-28
CRANKSET
FSA Gossamer BB30
CHAINRINGS
52/36
BOTTOM BRACKET
OS integrated
CHAIN
KMC X10 CP
FRONT BRAKE
Specialized Shiv Aero
REAR BRAKE
Specialized Shiv Aero
BRAKE LEVERS
TRP TL720 Aero lever
PEDALS
Nylon flat test ride, loose-ball, w/ reflectors
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
XS | S | M | L | XL | |
---|---|---|---|---|---|
Seat-Tube Angle | 77° | 77° | 77° | 77° | 77° |
Head-Tube Length | 99mm | 115mm | 139mm | 163mm | 189mm |
Seat Tube Length, BB Center to Top | 505mm | 525mm | 551mm | 577mm | 603mm |
Seat-Post Length | 350mm | 350mm | 350mm | 350mm | 350mm |
Seat Post Setback | 12.5mm | 12.5mm | 12.5mm | 12.5mm | 12.5mm |
Head-Tube Angle | 70.25° | 71.5° | 72° | 72.5° | 72.5° |
Chain-Stay Length | 395mm | 395mm | 395mm | 395mm | 395mm |
Frame Reach | 365mm | 385mm | 405mm | 425mm | 445mm |
Front-Center | 573mm | 589mm | 608mm | 631mm | 659mm |
Frame Stack | 495mm | 515mm | 540mm | 565mm | 590mm |
Top Tube Length | 481mm | 504mm | 530mm | 557mm | 582mm |
Stand-Over Height | 752mm | 772mm | 797mm | 822mm | 847mm |
Fork Rake | 50mm | 50mm | 45mm | 45mm | 45mm |
B-B Drop | 72mm | 72mm | 72mm | 72mm | 72mm |
Trail | 69mm | 61mm | 63mm | 60mm | 60mm |
Wheelbase | 957mm | 973mm | 992mm | 1016mm | 1043mm |
Crank Length | 165mm | 170mm | 172.5mm | 172.5mm | 175mm |
