2014 Enduro Comp 26
5
1 Reviews
The 165mm-travel, M5 aluminium Enduro Comp 26 features FSR suspension, a custom…
Product Details
The 165mm-travel, M5 aluminium Enduro Comp 26 features FSR suspension, a custom Fox Float CTD Evolution shock with AUTOSAG and RockShox Pike RC fork. Climb higher, descend faster.
Custom tuned FOX Float CTD Evolution shock with AUTOSAG features three compression settings: Climb, Trail and Descend
Custom SRAM S-1250 AM double crankset with PF30 spindle and shift guard, plus SRAM's 11-36 cassette for high-performance shifting and chain retention
2Bliss Ready Specialized Butcher Control 2.3" dual compound front tyre for premium control on challenging trail conditions
The fully manipulated M5 alloy FSR frame with ORE tubing is the centrepiece of this incredibly versatile 165mm-travel design, featuring an improved shock link, sealed cartridge bearing pivots, 142+ dropouts, ISCG '05 mount, and replaceable derailleur hanger
The fully manipulated M5 alloy FSR frame with ORE tubing is the centrepiece of this incredibly versatile 165mm-travel design, featuring an improved shock link, sealed cartridge bearing pivots, 142+ dropouts, ISCG '05 mount, and replaceable derailleur hanger
The fully manipulated M5 alloy FSR frame with ORE tubing is the centrepiece of this incredibly versatile 165mm-travel design, featuring an improved shock link, sealed cartridge bearing pivots, 142+ dropouts, ISCG '05 mount, and replaceable derailleur hanger
Technical Specifications
FRAMESET
FRAME
M5 aluminium, tapered headtube, PF30 BB, ISCG '05 mount, internal Command Post BlackLite routing, 142+ dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 165mm travel
SWAT
Bottle cage w/ SWAT Technology compatible (not included)
HEADSET
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
SEAT BINDER
Specialized 7050 hard anodised alloy collar w/ QR, 34.9mm
SUSPENSION
REAR SHOCK
Custom FOX Float CTD Evolution w/ AUTOSAG, Climb, Trail, Descend settings and reb adj., 215.9mm x 57.2mm
FORK
RockShox Pike, Solo Air spring, tapered alloy steerer, comp and reb adj., 15mm thru-axle, 160mm travel
WHEELS
RIMS
Roval 26, alloy disc, 23mm internal width, 32h
FRONT HUB
Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 32h
REAR HUB
Specialized Hi Lo disc, 4x-sealed cartridge bearings, 12mm thru-axle, 142+ spacing, 32h
SPOKES
DT Industry Stainless, 3X front/rear 2.0mm
FRONT TYRE
Specialized Butcher Control, 2Bliss Ready, 26x2.3", foldable aramid bead, 60TPI
REAR TYRE
Specialized Purgatory Control, 2Bliss Ready, 26x2.3", foldable aramid bead, dual-compound, 60 TPI
DRIVETRAIN
FRONT DERAILLEUR
SRAM X7, 10-speed, S3 direct mount for DMD, bottom pull
REAR DERAILLEUR
SRAM X9 Type 2, 10-speed, mid cage
SHIFT LEVERS
SRAM X7, 10-speed, trigger, w/ MatchMaker clamp
CASSETTE
SRAM PG-1030, 10-speed, 11-36
CHAIN
SRAM PC 1031, 10-speed, PowerLink
CRANKSET
Custom SRAM S-1250, 7050 alloy arms, 10-speed AM double, PF30 spindle, S: 170mm, Others: 175mm
CHAINRINGS
36/24
BOTTOM BRACKET
SRAM PF30, OS press-in bearings, sealed cartridge
COCKPIT
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Specialized 2014 butted alloy, single bolt setback, 30.9mm, S/M: 350mm, Others: 400mm
STEM
Specialized Trail, 6061 alloy, 4-bolt, 6-degree rise, 31.8mm clamp
HANDLEBARS
Specialized All-Mountain, low-rise, 7050 alloy, 750mm wide, 8-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
BRAKES
FRONT BRAKE
Formula C1, alloy calliper, metallic pad, 200mm rotor
REAR BRAKE
Formula C1, alloy calliper, metallic pad, 180mm rotor
BRAKE LEVERS
Formula C1, hydraulic disc, tooled reach adj.
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | |
|---|---|---|---|
| Ground-Top | 918mm | 928mm | 936mm |
| Bottom Bracket Height - Low Setting | 351mm | 351mm | 351mm |
| Top Tube Length (Horizontal) | 558mm | 588mm | 617mm |
| Seat Tube Angle (Effective) | 75° | 75° | 75° |
| Head Tube Height | 110mm | 120mm | 130mm |
| Top Tube Length (Actual) | 516mm | 546mm | 573mm |
| Seat Tube Angle (Actual) | 69.5° | 69.6° | 69.7° |
| Seat Tube Length - Center to Top | 396mm | 430mm | 468mm |
| Wheel Base | 1121mm | 1153mm | 1183mm |
| Standover Height | 757mm | 767mm | 775mm |
| Stack | 567mm | 577mm | 585mm |
| Reach | 404mm | 431mm | 457mm |
| Head Tube Angle | 66.5° | 66.5° | 66.5° |
| Chainstay Length | 419mm | 419mm | 419mm |
| Crank Length | 170mm | 175mm | 175mm |
| Handlebar Width | 720mm | 720mm | 720mm |
| Stem Length | 60mm | 60mm | 75mm |
| Seatpost Length | 350mm | 400mm | 400mm |
