2011 Crosstrail Comp Disc
5
1 Reviews
Shimano disc brakes and 9-speed drivetrain make an already versatile bike even more…
Colour:
Black/White
What's my size?
Select a Size
Product Details
Shimano disc brakes and 9-speed drivetrain make an already versatile bike even more capable and fun to ride.
Alloy V-brakes provide easily adjustable, uncomplicated stopping power
Specialized Borough XC Sport 700c tyres roll fast, yet have enough bite for the trail
Smooth-welded A1 Premium Aluminium frame for lightweight confidence on any surface, with fender/rack braze-ons for versatility
BG Crosstrail saddle has front/rear bumpers for on and off-road durability and ample padding for comfort
75mm-travel coil-sprung fork with alloy lowers allows this hybrid to go off-road with ease
75mm-travel coil-sprung fork with alloy lowers allows this hybrid to go off-road with ease
75mm-travel coil-sprung fork with alloy lowers allows this hybrid to go off-road with ease
Gentle riserbar encourages a comfortable and confident athletic position, and BG Contour MTB grips keep hands pain-free and loose on long rides
Specialized Borough XC Sport 700c tyres roll fast, yet have enough bite for the trail
Durable, double-walled 700c alloy rims can handle varied terrain
75mm-travel coil-sprung fork with alloy lowers allows this hybrid to go off-road with ease
Technical Specifications
FRAMESET
FRAME
Specialized A1 Premium Aluminium w/ smooth welding, w/ fender and rack braze-ons, forged drop outs w/ kickstand mount
HEADSET
Ahead, loose ball, Cr-Mo cups, 25.5mm stack
SEAT BINDER
Forged alloy
SUSPENSION
REAR SHOCK
FORK
SR SunTour SF11-NRX-D-LO, mag. lower, Cr-Mo stanchions, hydraulic LO
WHEELS
RIMS
Alloy double wall, pinned, disc mount w/ eyelets, 32h
FRONT HUB
Machined disc side flange and mount, sealed bearings, dual lock nuts w/ 19mm contact side
REAR HUB
Machined disc mount & flanges, doubel sealed, ground race, dual lock nuts w/ 19mm contact side
SPOKES
2mm (14g) stainless
FRONT TIRE
Specialized Borough XC Sport, 700x45c, 60TPI, wire bead
REAR TIRE
Specialized Borough XC Sport, 700x45c, 60TPI, wire bead
INNER TUBES
Schraeder valve
DRIVETRAIN
FRONT DERAILLEUR
Shimano Alivio, 31.8mm clamp, top swing, dual pull
REAR DERAILLEUR
Shimano Alivio, 9-speed
SHIFT LEVERS
Shimano Alivio, 9-speed rapid-fire
CASSETTE
Shimano 9-speed
CHAIN
KMC X9 w/ reusable Missing Link
CRANKSET
SR SunTour Octalink spline, replaceable rings, w/composite anti-jump disc
CHAINRINGS
48A x 36S x 26T w/ chainguard
BOTTOM BRACKET
Octalink spline 68mm
COCKPIT
SEATPOST
Alloy, 2-bolt head, 12.5mm offset, 27.2mm
STEM
3D forged alloy, 6 degree rise, 31.8mm clamp
HANDLEBARS
Butted alloy riser bar, 31.8mm, 25mm rise, 8 degree back sweep, 6 degree up
GRIPS
BG Contour, closed end, 132mm
SADDLE
Specialized XC, Body Geometry, 143mm width, front and rear bumpers
BRAKES
FRONT BRAKE
Shimano BRM-445 hydraulic disc brake w/ 160mm rotors
REAR BRAKE
Shimano BRM-445 hydraulic disc brake w/ 160mm rotors
BRAKE LEVERS
Hydraulic lever, included w/brake
ACCESSORIES
PEDALS
Super light alloy, loose ball, w/ reflectors
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | XL | XXL | |
|---|---|---|---|---|---|
| Ground-Top | 898mm | 910mm | 919mm | 931mm | 945mm |
| Bottom Bracket Height - Low Setting | 292mm | 292mm | 292mm | 292mm | 292mm |
| Top Tube Length (Horizontal) | 579mm | 594mm | 605mm | 620mm | 635mm |
| Head Tube Height | 90mm | 100mm | 110mm | 120mm | 135mm |
| Head Tube Angle - Low Setting | 69.5° | 70° | 70° | 70.5° | 70.5° |
| Seat Tube Angle (Actual) - Low Setting | 74° | 74° | 74° | 73.5° | 72.5° |
| Top Tube Length (Actual) | 569mm | 578mm | 585mm | 597mm | 612mm |
| Seat Tube Length - Center to Top | 394mm | 445mm | 483mm | 533mm | 584mm |
| Wheel Base | 1111mm | 1121mm | 1133mm | 1138mm | 1141mm |
| Standover Height | 744mm | 779mm | 804mm | 838mm | 869mm |
| Stack | 606mm | 618mm | 627mm | 639mm | 653mm |
| Reach | 405mm | 417mm | 425mm | 431mm | 429mm |
| Chainstay Length | 459mm | 459mm | 459mm | 459mm | 459mm |
