2011 Allez Elite Compact
0 Reviews
Specialized E5 frame with tapered head tube saves weight and improves steering p…
Product Details
Specialized E5 frame with tapered head tube saves weight and improves steering precision.
Oversized aluminum handlebar is stiff and light for serious performance
Smooth, precise Shimano Tiagra STI shifters offer effortless and reliable performance
Race-inspired E5 smooth-welded alloy frame with integrated headset is stiff, light, and fast
Adjustable 4-position oversized alloy stem with 31.8mm bar clamp for strength and versatile positioning
Ultralight FACT carbon fork and stiff tapered steerer provides precise steering through the tightest turns
Technical Specifications
FRAMESET
FRAME
Specialized E5 aluminum, fully manipulated tubing, smooth weld compact race design, 1.5"" integrated headset
FORK
Specialized FACT carbon, carbon legs, aluminum crown and steerer, 1.5"" lower bearing
HEADSET
1-1/8"" upper and 1-1/5"" lower Cr-Mo cartridge bearings integrated w/ headset, 20mm cone spacer with 20mm of spacers
SEAT BINDER
Alloy, 31.8mm
WHEELS
RIMS
Mavic CXP22
FRONT HUB
Forged alloy Hub, sealed bearings, 28 hole, for J bend round spokes
REAR HUB
Forged aluminum, 32h, double sealed ball bearings, cassette, QR
SPOKES
Stainless 14g
FRONT TIRE
Specialized All Condition, 700x23c, aramid bead, 60TPI, w/ Flak Jacket protection
REAR TIRE
Specialized All Condition, 700x23c, aramid bead, 60TPI, w/ Flak Jacket protection
INNER TUBES
Standard presta valve
DRIVETRAIN
SHIFT LEVERS
Shimano Tiagra STI
FRONT DERAILLEUR
Shimano Tiagra
REAR DERAILLEUR
Shimano Tiagra
CASSETTE
Shimano HG-50, 9-speed, 12-25t
CRANKSET
Shimano Tiagra
CHAINRINGS
50 x 34T
BOTTOM BRACKET
With crankset
CHAIN
KMC X9
COCKPIT
HANDLEBARS
Specialized Elite, 6061 aluminum, 130 drop, 90 reach, 31.8mm
STEM
Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
TAPE
Specialized S-Wrap, w/ gel
SADDLE
Body Geometry Riva Road, w/ steel rails
SEATPOST
Specialized Elite, carbon wrapped alloy, two-bolt clamp, 27.2mm
BRAKES
FRONT BRAKE
Tektro cold-forged, dual pivot w/ cartridge pads
REAR BRAKE
Tektro cold-forged, dual pivot w/ cartridge pads
BRAKE LEVERS
Shimano Tiagra STI
ACCESSORIES
PEDALS
Black cage, body & toe clips w/ strap
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Seat-Tube Angle | 75.5° | 74° | 73.5° | 73.25° | 73° | 72.5° |
| Head-Tube Length | 100mm | 120mm | 145mm | 170mm | 205mm | 230mm |
| Seat-Post Length | 300mm | 350mm | 350mm | 350mm | 350mm | 350mm |
| Head-Tube Angle | 72.25° | 73° | 73° | 73.5° | 73.5° | 74° |
| Chain-Stay Length | 405mm | 405mm | 405mm | 405mm | 407mm | 410mm |
| Top-Tube Length, Horizontal | 518mm | 537mm | 548mm | 565mm | 582mm | 600mm |
| Front-Center | 576mm | 576mm | 583mm | 591mm | 605mm | 613mm |
| Handle-Bar Width | 400mm | 420mm | 420mm | 420mm | 440mm | 440mm |
| Stand-Over Height | 737mm | 777mm | 798mm | 816mm | 836mm | 863mm |
| Seat-Tube Length, B-B Center to Top | 460mm | 490mm | 510mm | 530mm | 550mm | 580mm |
| Fork Rake | 45mm | 45mm | 45mm | 43mm | 43mm | 43mm |
| B-B Drop | 71.5mm | 71.5mm | 69mm | 69mm | 67.5mm | 67.5mm |
| Trail | 62mm | 57mm | 57mm | 56mm | 56mm | 53mm |
| Wheelbase | 970mm | 970mm | 978mm | 986mm | 1003mm | 1013mm |
| Crank Length | 170mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Stem Length | 75mm | 90mm | 100mm | 100mm | 110mm | 110mm |
