2011 Stumpjumper Comp

0 Bewertungen

Vom Start weg renntauglich und somit ideal für XC-Biker, die schneller klettern und…

Farbe:

White/Black

Was ist meine Größe?

Imperial

Metrisch

Größe eingeben

Höhe:

Schienbeinlänge messen

Wähle eine Grösse

Produktdetails

Vom Start weg renntauglich und somit ideal für XC-Biker, die schneller klettern und im Singletrack-Slalom brillieren wollen.

Fully manipulated M5 alloy HT frame with curved top tube looks as fast and sweet as it rides due to its race-optimized geometry
RockShox Reba RLT with 90mm travel, rebound/compression adjust, and Floodgate control is stiff, smooth, and fast for flying up hills
Custom DT Swiss X420SL 24mm-wide rims are sleeved and eyeletted for a sturdy and lightweight package that makes the climb out effortless
Specialized BG Phenom Comp saddle with hollow Cr-Mo rails is a lightweight and minimalist design, tuned for sit bone flex and comfortable climbing
Custom Avid Elixir R SL lightweight hydraulic disc brakes/levers with alloy backed semi-metallic pads and tool-less reach adjust for superb control and modulation
S-Works The Captain 2.0" front and S-Works Fast Trak 2.0" rear 2Bliss Ready dual compound tires work together to deliver exceptional speed and traction, while minimizing rotating weight

Technische Spezifikationen

FRAMESET

FRAME

M5 fully manipulated alloy, curved TT, SS w/ disc brake mount

HEADSET

1-1/8"" upper and lower campy style cartridge bearings for integrated alloy HT

SEAT BINDER

34.9mm clamp ID, 7050 hard annodized alloy collar w/ QR, black

SUSPENSION

FORK

RockShox Reba RLT, tapered alloy steerer, compression and rebound adj. LO w/external floodgate adj., standard drop-outs, 90mm travel

WHEELS

RIMS

Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h

FRONT HUB

Specialized Hi Lo disc, laser-etched logo, OS 28 end caps, sealed cartridge bearing, RWS, 28h

REAR HUB

Specialized Hi Lo disc, laser-etched logo, double sealed cartridge bearing, QR, 32h

SPOKES

DT Swiss Champion 1.8mm (15g) stainless

FRONT TIRE

S-Works ""The Captain"", 120 TPI, 2Bliss ready aramid bead, dual compound, 26x2.0""

REAR TIRE

S-Works Fast Trak LK, 120 TPI, 2Bliss ready aramid bead, dual compound, 26x2.0""

INNER TUBES

Ultralight presta valve

DRIVETRAIN

FRONT DERAILLEUR

SRAM X.7, 10-speed, 34.9 clamp mount, top pull

REAR DERAILLEUR

SRAM X.9, 10-speed, long cage

SHIFT LEVERS

SRAM X.7, 10-speed, aluminum trigger

CASSETTE

Shimano HG81, 10-speed, 11-36t

CHAIN

KMC X10, 10-speed, w/ reuseable Missing Link, nickel plates

CRANKSET

Custom SRAM S-1250, 7050 alloy arms, 10-speed triple, GXP spindle, 15.5: 170mm, others: 175mm

CHAINRINGS

44A x 33A x 22A, 4-bolt, 104/64mm

BOTTOM BRACKET

SRAM GXP, outboard bearing

COCKPIT

SEATPOST

2014 butted alloy, single bolt setback, 30.9mm, 15.5/17.5"": 350mm, others: 400mm

STEM

Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise

HANDLEBARS

Specialized XC flat bar, 6061 butted alloy, 660mm wide, 8 degree back sweep, 31.8mm

GRIPS

Specialized lock-on, S/M: Grappler, Other: Rocca

SADDLE

Specialized BG Phenom Comp, hollow Cr-Mo rails, 143mm width

BRAKES

FRONT BRAKE

Custom Avid Elixir R SL, hydraulic disc, tool-less reach adjust, alloy backed semi-metallic pads, stainless hardware, G3 Clean Sweep rotor, 160mm rotor

REAR BRAKE

Custom Avid Elixir R SL, hydraulic disc, tool-less reach adjust, alloy backed semi-metallic pads, stainless hardware, G3 Clean Sweep rotor, 15.5/17.5: 140mm, 19/21: 160mm rotor

BRAKE LEVERS

Custom Avid Elixir R SL hydraulic, tool-less reach adj.

ACCESSORIES

PEDALS

Resin Test Ride Pedals with toe clips, CEN std.

*Gewichte basieren auf der Produktion lackierter Rahmen, wie abgebildet. Tatsächliche Gewichte variieren je nach Farbgebung, Rahmengrösse und Komponentenvariation. Spezifikationen können ohne Vorankündigung geändert werden.

Geometrie

	15.5	17.5	19	21
Mitte Tretlager - Mitte Vorderachse	878mm	896mm	915mm	934mm
Tretlagerhöhe 650x2.8"	304mm	304mm	304mm	304mm
Oberrohrlänge (horizontal)	555mm	590mm	615mm	640mm
Steuerrohrhöhe	120mm	140mm	160mm	180mm
Vorlauf	70.5°	70.5°	70.5°	70.5°
Radstand	73°	73°	73°	73°
Oberrohrlänge tatsächlich	538mm	567mm	590mm	614mm
Seat Tube Length - Center to Top	394mm	445mm	483mm	533mm
Radstand	1034mm	1070mm	1096mm	1122mm
Überstandshöhe	741mm	780mm	811mm	846mm
Stack	574mm	592mm	611mm	630mm
Reach	380mm	409mm	428mm	447mm
Kettenstreben-Länge	424mm	424mm	424mm	424mm
Kurbellänge	170mm	175mm	175mm	175mm
Lenkerbreite	660mm	660mm	660mm	660mm
Vorbaulänge	75mm	90mm	105mm	105mm
Länge Sattelstütze	350mm	350mm	400mm	400mm
