2019 Crossroads Sport
$699.00
5
4 Reviews
We might be biased, but we believe that bikes are the best tool to help you along…
Product Details
We might be biased, but we believe that bikes are the best tool to help you along your fitness journey, and the Crossroads Sport is no exception.
Built with a component package that you can rely on, the Crossroads Sport is the perfect bike to add to your life. It's purpose-built to help you on your fitness journey, and its wide 45mm tires deliver confident handling for when you're speeding along the bike path. And when you add in the strength, weight, and versatility of its aluminum frame, plus rack and fender mounts, this bike truly earns its keep in your household.
So get out there, enjoy the sunshine, and achieve your goals with the Crossroads Sport.
The sturdy A1 Premium Aluminum frame, combined with a steel fork and rack/fender mounts, delivers reliable handling for a confident ride and plenty of options for carrying your goodies.
The Body Geometry Comfort saddle provides comfort and support, while also reducing soft tissue pressure.
Durable and wide 700x45mm Specialized Borough Armadillo tires provide a stable ride on dirt paths and roads, and feature super-tough Armadillo puncture protection.
Technical Specifications
FRAMESET
FRAME
Specialized A1 Premium Aluminum, fender/rack mounts
SUSPENSION
FORK
Steel, fender/rack mounts
COCKPIT
HANDLEBARS
Alloy, 15-degree backsweep, 4-degree upsweep, 60mm rise, 25.4mm
GRIPS
Specialized Body Geometry Contour, lock-on
SEATPOST
Spring suspension, alloy, 27.2mm, 2-bolt clamp
SEAT BINDER
Quick-release type, 31.8mm
BRAKES
FRONT BRAKE
V-brake, linear pull
REAR BRAKE
V-brake, linear pull
DRIVETRAIN
FRONT DERAILLEUR
Shimano Tourney, 3-speed, top-swing
REAR DERAILLEUR
Shimano Altus, 7-/8-speed
CASSETTE
Shimano Altus, 8-speed, 11-32t
CRANKSET
Shimano Tourney FC-TY701, 3-piece, square taper
CHAINRINGS
48/38/28T
BOTTOM BRACKET
Square-taper, 68mm shell, 119mm length
CHAIN
KMC Z8, 8-speed w/ reusable Missing Link™
SHIFT LEVERS
Shimano EF500, EZ-Fire Plus, 8-speed
WHEELS & TIRES
RIMS
700C, 6061 aluminum, double-wall
FRONT HUB
Alloy, loose ball bearings, quick-release, 32h
REAR HUB
Alloy, 8-speed freehub, loose ball bearings, bolt-type, 32h
SPOKES
Stainless, 14g
FRONT TIRE
Borough, 700x45mm, 60 TPI, BlackBelt protection
REAR TIRE
Borough, 700x45mm, 60 TPI, BlackBelt protection
INNER TUBES
Presta valve
ACCESSORIES
PEDALS
Specialized Body Geometry
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | XL | XXL | |
|---|---|---|---|---|---|
| Crank Length | 170mm | 170mm | 170mm | 175mm | 175mm |
| Handlebar Width | 645mm | 645mm | 685mm | 685mm | 685mm |
| Stem Length | 85mm | 105mm | 105mm | 105mm | 105mm |
| Saddle Width | 200mm | 200mm | 200mm | 200mm | 200mm |
| Seatpost Length | 300mm | 350mm | 350mm | 350mm | 350mm |
| Stack | 577mm | 611mm | 625mm | 639mm | 658mm |
| Reach | 401mm | 405mm | 415mm | 425mm | 433mm |
| Head Tube Length | 145mm | 175mm | 190mm | 205mm | 225mm |
| Head Tube Angle | 69.5° | 70.5° | 70.5° | 70.5° | 70.5° |
| BB Height | 291mm | 291mm | 291mm | 291mm | 291mm |
| BB Drop | 65mm | 65mm | 65mm | 65mm | 65mm |
| Trail | 74mm | 72mm | 72mm | 72mm | 72mm |
| Fork Length, Full | 410mm | 410mm | 410mm | 410mm | 410mm |
| Fork Rake/Offset | 55mm | 51mm | 51mm | 51mm | 51mm |
| Front Center | 655mm | 655mm | 670mm | 685mm | 701mm |
| Chainstay Length | 465mm | 465mm | 465mm | 465mm | 465mm |
| Wheelbase | 1112mm | 1113mm | 1128mm | 1143mm | 1158mm |
| Top Tube Length, Horizontal | 600mm | 615mm | 630mm | 645mm | 660mm |
| Bike Standover Height | 718.3mm | 755.5mm | 790.5mm | 831.5mm | 880mm |
| Seat Tube Length | 385mm | 430mm | 480mm | 540mm | 610mm |
| Seat Tube Angle | 71° | 71° | 71° | 71° | 71° |
Manual Downloads
For safety warnings please refer to the documentation in the Manual Downloads section of this page.
