2008 BigHit FSR Frame
0 Reviews
Freeride/DH IT'S LIKE THAT With an A1 aluminum chassis, sealed bearing pivots and…
Color:
Gloss Black/Red
What's my size?
Select a Size
Product Details
Freeride/DH IT'S LIKE THAT With an A1 aluminum chassis, sealed bearing pivots and custom tuned suspension components, every Big Hit is purpose built for showing people how it is.Inside Tech Every BigHit is built to go big, with many of the same features found on our trailblazing Demo line of freeride machines. Just like the Demo, our BigHit features ORE top and down tubes for enhanced handling and low weight, cartridge bearings at all pivots for maximum durability and adjustable geometry for customized control.
BigHit FSR frame, A1 Premium Aluminum ORE TT/DT, full cartridge bearing pivots, ISCG mount, asymetrical rear triangle
26" F/R wheel, 8.2" travel, adj geometry
Fox DHX 4.0 shock
Technical Specifications
FRAMESET
FRAME
BigHit FSR, A1 Premium Aluminum ORE TT/DT, full cartridge bearing pivots, ISCG mount, asymetrical rear triangle, 26"" F/R wheel, 8.2"" travel, adj. geometry
SEAT BINDER
Alloy collar w/ QR, 34.9mm clamp ID
SUSPENSION
REAR SHOCK
Fox DHX 4.0, 8.75x2.75"", adjustable rebound, ProPedal, IFP pressure, S:400, M:450, L:500
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | |
|---|---|---|---|
| Bottom Bracket Height - Low Setting | 362mm | 362mm | 362mm |
| Top Tube Length (Horizontal) | 560mm | 585mm | 613mm |
| Head Tube Height | 120mm | 120mm | 120mm |
| Head Tube Angle - Low Setting | 66° | 66° | 66° |
| Seat Tube Angle (Actual) - Low Setting | 61° | 61° | 61° |
| Seat Tube Angle (Effective) - Low Setting | 75° | 75° | 75° |
| Top Tube Length (Actual) | 499mm | 524mm | 549mm |
| Head Tube Angle - High Setting | 68° | 68° | 68° |
| Bottom Bracket Height - High Setting | 387mm | 387mm | 387mm |
| Seat Tube Angle (Actual) - High Setting | 63° | 63° | 63° |
| Seat Tube Angle (Effective) - High Setting | 76° | 76° | 76° |
| Seat Tube Length - Center to Top | 457mm | 457mm | 483mm |
| Wheel Base | 1130mm | 1148mm | 1164mm |
| Standover Height | 776mm | 777mm | 779mm |
| Chainstay Length | 428mm | 428mm | 428mm |
| Crank Length | 170mm | 170mm | 170mm |
| Handlebar Width | 680mm | 680mm | 680mm |
| Stem Length | 40mm | 40mm | 40mm |
| Seatpost Length | 300mm | 300mm | 300mm |
