2010 Tarmac Comp Double Rival
0 Reviews
Leading our pros to victory at races like Liège-Bastogne-Liège, Tour of Flanders,…
Product Details
Leading our pros to victory at races like Liège-Bastogne-Liège, Tour of Flanders, and countless others, the Tarmac® proves itself to be the best handling, most high-performance bike on the road. Thanks to the integration of critical components, an extremely rigid FACT carbon frame, and proprietary Body Geometry extras, we can proudly say that nothing is lighter and stiffer.
FACT full carbon monocoque fork is stiff and lightweight with a 1.5" lower headset bearing
FACT carbon Pave seatpost uses a Zertz insert to minimize road vibrations for greater comfort
Adjustable 4-position, 3D-forged alloy stem with 31.8mm bar clamp for strength and versatile positioning
Specialized Pro ergonomic alloy handlebars for a comfortable, natural position, no matter how long the ride
Body Geometry Toupe saddle features a carbon reinforced shell and hollow Cr-Mo rails for balanced stiffness and compliance on longer rides
Lightweight, efficient and stiff, the Tarmac FACT 8r carbon triple monocoque frame is engineered with one goal--to get to the podium fastest
Technical Specifications
FRAMESET
FRAME
Specialized Tarmac FACT 8r carbon, triple monocoque construction, compact race design
FORK
Tarmac full FACT carbon monocoque
HEADSET
Campy style, 1 1/8-1 1/2"", steel race
SEAT BINDER
Forged alloy, 32.6mm
WHEELS
FRONT TIRE
Specialized Mondo Pro II, 700x23c, aramid bead, 120TPI, w/ Flak Jacket protection
REAR TIRE
Specialized Mondo Pro II, 700x23c, aramid bead, 120TPI, w/ Flak Jacket protection
INNER TUBES
Standard presta valve
FRONT WHEEL
Mavic Aksium
REAR WHEEL
Mavic Aksium
DRIVETRAIN
FRONT DERAILLEUR
SRAM Rival
REAR DERAILLEUR
SRAM Rival
SHIFT LEVERS
SRAM Rival
CASSETTE
Shimano 105, 10-speed, 12-27t
CHAIN
SRAM PC-1050
CRANKSET
SRAM S300 crankset
CHAINRINGS
53 x 39T
BOTTOM BRACKET
With Crankset
COCKPIT
STEM
Specialized Comp-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
HANDLEBARS
Specialized Pro Ergo 2014 alloy
TAPE
Specialized S-Wrap, cork ribbon w/ 2.5 gel pads
SADDLE
Body Geometry Toupe w/ hollow Cr-Mo rails
SEATPOST
Specialized Expert, FACT carbon w/ Zertz insert, aluminum head, two-bolt clamp, 27.2mm
BRAKES
FRONT BRAKE
SRAM Rival
REAR BRAKE
SRAM Rival
BRAKE LEVERS
SRAM Rival
ACCESSORIES
PEDALS
Silver cage/black body, w/ black toe clips and strap
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Seat-Tube Angle | 75.5° | 74° | 73.5° | 73.25° | 73° | 72.5° |
| Head-Tube Length | 100mm | 120mm | 145mm | 170mm | 205mm | 230mm |
| Seat-Post Length | 300mm | 350mm | 350mm | 350mm | 350mm | 350mm |
| Head-Tube Angle | 72.25° | 73° | 73° | 73.5° | 73.5° | 74° |
| Chain-Stay Length | 405mm | 405mm | 405mm | 405mm | 407mm | 410mm |
| Top-Tube Length, Horizontal | 518mm | 537mm | 548mm | 565mm | 582mm | 600mm |
| Front-Center | 576mm | 576mm | 583mm | 591mm | 605mm | 613mm |
| Handle-Bar Width | 400mm | 420mm | 420mm | 420mm | 440mm | 440mm |
| Stand-Over Height | 730mm | 755mm | 777mm | 800mm | 828mm | 857mm |
| Seat-Tube Length, B-B Center to Top | 460mm | 490mm | 510mm | 530mm | 550mm | 580mm |
| Fork Rake | 45mm | 45mm | 45mm | 43mm | 43mm | 43mm |
| B-B Drop | 71.5mm | 71.5mm | 69mm | 69mm | 67.5mm | 67.5mm |
| Trail | 62mm | 57mm | 57mm | 56mm | 56mm | 53mm |
| Wheelbase | 941mm | 961mm | 973mm | 988mm | 1008mm | 1030mm |
| Crank Length | 170mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Stem Length | 75mm | 90mm | 100mm | 100mm | 110mm | 120mm |
