STATUS 2 170 Frameset

0 Reviews

STATUS 2 finds the boundaries of mountain bikes and pushes past them. Is it a trail…

Complete Your Ride
Remove Icon
Delivery Icon

We deliver! Just say when and how.

Simplicity

Simplicity

STATUS 2 170 was designed to be dead simple and ready to deliver, regardless of terrain. The Ride Dynamics team developed the kinematics and dialed in the geo to deliver a snappy, poppy bike that’s at home on both technical singletrack and gapping a set of stairs.

Durability

Durability

Each build starts with a super strong M5 alloy chassis and tough alloy wheels. Stout suspension, powerful brakes, and popular drivetrain options round out these builds to catch big hits, pedal smooth, and provide a ton of stoppage.

Ride Quality

Ride Quality

With updated, aggressive trail geometry and impressively short but scaling chainstays, STATUS 2 170 is just flat-out fun on the gnarliest terrain. There’s plenty of composure when you need it on big hits and chunk—with the freedom to do your thing when you want it.

Product Details

Add Icon

STATUS 2 finds the boundaries of mountain bikes and pushes past them. Is it a trail bike? Yes. Park bike? Yep. Cruise to the convenience store and stop for a stealth session on a concrete wall ride? Oh yeah. STATUS 2 is a bike meant to be ridden, however, or wherever you ride.

Whether you're on the trails, at the bike park, on the streets, or just cutting turns with your friends on a local hill, the STATUS 2 will allow you to ride your way.

BUILT BY RIDERS: Each build starts with a super strong M5 alloy chassis and tough alloy wheels. Stout suspension, powerful brakes, and popular drivetrain options round out these builds to catch big hits, pedal smooth, and provide a ton of stoppage. It’s not for the gram counter—it’s for those riders who push the boundaries of progression and come back for more.

RIDE DYNAMICS TUNED: Before arriving at your doorstep or local bike shop, each STATUS 2 gets a special shock tune from our Specialized Ride Dynamics team—a group that eats, sleeps, and breathes mountain bike suspension. The shock's characteristics are designed to complement the kinematics of the new STATUS 2 perfectly.

LET’S GET PERSONAL: Each model of STATUS 2 features neatly packaged flip chips (located on the Horst pivot link, close to the rear axle) that allow you to finely tune the frame’s geometry to your desired ride or terrain. Bikes ship in the high position but can be ‘flipped’ to lower and slacker—8 mm lower bottom bracket and half a degree slacker head tube angle.

  • 100% Redesigned durable alloy chassis

  • Horst Link geometry adjust flip chip

  • Updated geometry for more usability

Technical Specifications

Add Icon

Frameset

Frame

M5 Alloy chassis and rear-end, Trail Geometry, horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm of travel

Seat Binder

Alloy, 38.6mm

Suspension

Rear Shock

FOX DHX Performance, Ride Dynamics Trail Tune, S1:230x60mm, S2-S5:230x62.5mm

Product Details

Product ID

221255

Weight

Weight

4.77kg (10 lb, 8.3 oz)

Weight Size

S3

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

Add Icon
S1S2S3S4S5
Stack (low)620mm625mm634mm643mm652mm
Stack (high)616mm620mm629mm638mm647mm
Reach (low)420mm445mm470mm495mm520mm
Reach (high)426mm451mm476mm501mm526mm
Headtube Length95mm100mm110mm120mm130mm
Headtube Angle (low)63.5°63.5°63.5°63.5°63.5°
Headtube Angle (high)64°64°64°64°64°
BB Height (low)342mm342mm342mm342mm342mm
BB Height (high)350mm350mm350mm350mm350mm
BB Drop (low)34mm34mm34mm34mm34mm
BB Drop (high)26mm26mm26mm26mm26mm
Trail (low)138mm138mm138mm138mm138mm
Trail (high)133mm133mm133mm133mm133mm
Fork Length (full)581mm581mm581mm581mm581mm
Fork Rake/Offset44mm44mm44mm44mm44mm
Front Center762mm789mm819mm848mm878mm
Chainstay Length (low)432mm432mm432mm437mm437mm
Chainstay Length (high)428mm428mm428mm433mm433mm
Wheelbase1193mm1221mm1250mm1285mm1314mm
Top-tube Length (horizontal)554mm595mm635mm676mm716mm
Bike Standover Height735mm735mm742mm748mm752mm
Seat Tube Length390mm400mm420mm440mm465mm
Seat Tube Angle (low)77°77°77°77°77°
Seat Tube Angle (high)77.6°77.6°77.6°77.6°77.6°
Geometry
