2014 Secteur Sport
4.8
4 Reviews
Perfect for a Gran Fondo or epic weekend ride, the Secteur Sport's Endurance Road…
Product Details
Perfect for a Gran Fondo or epic weekend ride, the Secteur Sport's Endurance Road Geometry, FACT carbon fork with vibration-absorbing Zertz, and shaped tube sets delivers a ride that's stable, smooth, and quick. The upgraded wheelset and 9-speed Shimano Sora compact drivetrain add efficiency and reliability to any road adventure.
Specialized Comp shallow drop alloy bar for serious performance, wrapped with non-slip Specialized Roubaix tape for vibration damping
Lightweight, A1 Premium Aluminum, smooth-welded, butted frame features hydroformed, shaped seatstays with Zertz for great vertical compliance and a confident ride
Specialized FACT carbon fork with Zertz provides predictable steering and smooth handling
Never miss a critical shift with Shimano Sora STI shifters
AXIS Classic wheels balance weight and strength, fitted with Specialized Espoir Sport tires for a smooth ride
Technical Specifications
FRAMESET
FRAME
Specialized A1 Premium Aluminum w/ Zertz inserts, fully-manipulated tubing w/ smooth welds, 1-1/8"" lower bearing
FORK
Specialized FACT carbon w/ Zertz inserts, alloy steerer/crown, 1-1/8""
HEADSET
1-1/8"" sealed Cr-Mo cartridge bearings integrated w/ headset, 20mm alloy cone spacer, w/ 20mm of spacers
SEAT BINDER
Alloy, 31.8mm
WHEELS
FRONT WHEEL
AXIS Classic
REAR WHEEL
AXIS Classic
FRONT TIRE
Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x25c
REAR TIRE
Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x25c
INNER TUBES
Standard presta valve
DRIVETRAIN
SHIFT LEVERS
Shimano Sora STI
FRONT DERAILLEUR
Shimano Sora
REAR DERAILLEUR
Shimano Sora
CASSETTE
Shimano HG-50, 9-speed, 11-32
CRANKSET
FSA Tempo, 9-speed compact
CHAINRINGS
50/34
BOTTOM BRACKET
FSA, square taper, sealed cartridge bearings
CHAIN
KMC X9
COCKPIT
HANDLEBARS
Specialized Comp, shallow bend
STEM
Cast alloy, 4-bolt, 31.8mm clamp
TAPE
Specialized Roubaix, w/ 2.5mm gel pads, bar shapers
SADDLE
Body Geometry Riva Plus, Cr-Mo rails, 143mm
SEATPOST
Specialized Sport, alloy, 2-bolt, 27.2mm
BRAKES
FRONT BRAKE
Forged aluminum, dual pivot
REAR BRAKE
Forged aluminum, dual pivot
ACCESSORIES
PEDALS
Nylon flat test ride, loose ball, w/ reflectors
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 49.0 | 52.0 | 54.0 | 56.0 | 58.0 | 61.0 | 64.0 | |
|---|---|---|---|---|---|---|---|
| Seat-Tube Angle | 75.5° | 74° | 73.5° | 73.25° | 73° | 72.5° | 72.5° |
| Head-Tube Length | 125mm | 145mm | 165mm | 190mm | 225mm | 245mm | 260mm |
| Seat-Post Length | 350mm | 350mm | 350mm | 350mm | 350mm | 350mm | 350mm |
| Head-Tube Angle | 72° | 72° | 72° | 72.5° | 72.5° | 73° | 73° |
| Chain-Stay Length | 412mm | 412mm | 415mm | 415mm | 418mm | 420mm | 420mm |
| Top-Tube Length, Horizontal | 518mm | 537mm | 548mm | 565mm | 582mm | 600mm | 615mm |
| Front-Center | 582mm | 588mm | 595mm | 606mm | 621mm | 628mm | 643mm |
| Handle-Bar Width | 400mm | 420mm | 420mm | 420mm | 420mm | 440mm | 440mm |
| Stand-Over Height | 730mm | 756mm | 776mm | 798mm | 829mm | 851mm | 877mm |
| Seat-Tube Length, B-B Center to Top | 418mm | 447mm | 466mm | 485mm | 510mm | 535mm | 575mm |
| Fork Rake | 49mm | 49mm | 49mm | 49mm | 49mm | 49mm | 49mm |
| B-B Drop | 73mm | 73mm | 71.5mm | 71.5mm | 70mm | 70mm | 70mm |
| Stack | 528mm | 547mm | 564mm | 590mm | 622mm | 643mm | 657mm |
| Reach | 378mm | 378mm | 380mm | 387mm | 391mm | 398mm | 408mm |
| Trail | 59mm | 59mm | 59mm | 56mm | 56mm | 53mm | 53mm |
| Wheelbase | 983mm | 989mm | 1000mm | 1010mm | 1029mm | 1038mm | 1053mm |
| Crank Length | 170mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm | 175mm |
| Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm | 120mm |
