2020 S-Works Epic EVO
5
6 Reviews
Ever been in the middle of stage race or a massive backcountry ride and needed just…
Product Details
Ever been in the middle of stage race or a massive backcountry ride and needed just a little more margin for error on the descents? Yeah, we've been there, too. And that's why we made the perfect ultra-light, ultra-fast bike for precisely those situations.
A MORE EPIC KIND OF EPIC
Dropper posts and slightly longer forks may seem like overkill on an XC bike. We beg to differ. Epic EVOs are not only fast off the start line, they're even better suited to masochistically long rides, multi-day stage races, and fast backcountry missions.
HARDTAIL EFFICIENT. FULL-SUSPENSION CONTROL
Suspension should always make you faster—never slow you down with energy-sucking suspension bob. Our ingenious Brain-equipped shocks keep the Epic firm when the trail is smooth, then automatically turns your bike plush the moment your tires meet rocks and roots.
• S-Works, carbon chassis and ingenious Brain-equipped suspension—nothing’s faster.
• FOX Factory Step-Cast 34, with all the trimmings—including Fit4 damper and Kashima coating.
• Shimano XTR 12-speed drivetrain provides lightning-quick and precise shifts.
Technical Specifications
ACCESSORIES
SWAT
SWAT EMT Cage-Mount Tool
Pedals
PEDAL, TEST RIDE PEDALS PROVIDED BY SPECIALIZED
DRIVETRAIN
Rear Derailleur
Shimano XTR M9100, 12-speed, Shadow Plus
Shift Levers
Shimano XTR M9100, 12-speed
Cassette
Shimano XTR M9100, 12-speed, 10-51t
Chain
Shimano XTR M9100, 12-speed w/ quick link
Crankset
Race Face Next SL, 170/175mm
Chainrings
Steel, 30T
Bottom Bracket
Threaded, 30mm spindle
Suspension
Rear Shock
Custom RockShox Micro Brain shock w/ Spike Valve, AUTOSAG, 51x257mm
Fork
FOX Factory Step-Cast 34, Fit4 damper, Kashima, Boost™, 44mm offset, 120mm of travel
BRAKES
Front Brake
Shimano XTR Race M-9100
Rear Brake
Shimano XTR Race M-9100
WHEELS
Rims
Roval Control SL, hookless carbon, 25mm internal width, tubeless-ready, hand-built
Front Hub
Roval Control SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing, 24h
Rear Hub
Roval Control SL, DT Swiss Star Ratchet, 54t engagement, DT Swiss Microspline driver body, 12mm thru-axle, 148mm spacing, 28h
Spokes
DT Swiss Competition Race
Front Tire
Ground Control, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
Rear Tire
Fast Trak, GRID casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
Inner Tubes
Presta, 60mm valve
COCKPIT
SeatPost
FOX Factory Transfer, Kashima, Shimano Ispec-EV lever (S: 100mm, M-XL: 125mm)
Stem
S-Works SL, alloy, titanium bolts, 6-degree rise
Tape
Specialized Trail Grips
Handlebars
S-Works Carbon XC Mini Rise, 6-degree upsweep, 8-degree backsweep, 10mm rise, 760mm, 31.8mm
Saddle
Body Geometry S-Works Power, carbon fiber rails, carbon fiber base
FRAMESET
Frame
S-Works FACT 12m, XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 100mm of travel
Seat Binder
Specialized Alloy, 34.9mm, Titanium bolt
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Crank Length | 170mm | 175mm | 175mm | 175mm |
| Handlebar Width | 760mm | 760mm | 760mm | 760mm |
| Stem Length | 60mm | 75mm | 75mm | 75mm |
| Saddle Width | 155mm | 143mm | 143mm | 143mm |
| Seatpost Length | 361mm | 411mm | 411mm | 411mm |
| Stack | 595mm | 605mm | 619mm | 638mm |
| Reach | 398mm | 423mm | 446mm | 465mm |
| Head Tube Length | 95mm | 105mm | 120mm | 140mm |
| Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° |
| BB Height | 340mm | 340mm | 340mm | 340mm |
| BB Drop | 32mm | 32mm | 32mm | 32mm |
| Trail | 99mm | 99mm | 99mm | 99mm |
| Fork Length, Full | 526mm | 526mm | 526mm | 526mm |
| Fork Rake/Offset | 43mm | 43mm | 43mm | 43mm |
| Front Center | 667mm | 695mm | 723mm | 749mm |
| Chainstay Length | 438mm | 438mm | 438mm | 438mm |
| Wheelbase | 1103mm | 1132mm | 1159mm | 1186mm |
| Top Tube Length, Horizontal | 571mm | 599mm | 626mm | 650mm |
| Bike Standover Height | 772mm | 777mm | 782mm | 804mm |
| Seat Tube Length | 400mm | 434mm | 470mm | 520mm |
| Seat Tube Angle | 73.8° | 73.8° | 73.8° | 73.8° |
