2017 Roll Sport
5
1 Reviews
Have you ever been described as having caviar taste on a hotdog budget? We've all…
Product Details
Have you ever been described as having caviar taste on a hotdog budget? We've all been there, but we don't think you should have to sacrifice on any of the bells and whistles that get you excited to ride along your path to personal fitness. Meet the Roll Sport. It has everything you need to help achieve your goals, like a wide range of gears, a comfortable, upright geometry, wide, grippy tires, and a whole host of components that are built to withstand years of riding. You don't have to sacrifice, you just need the Roll Sport.
Wide diameter, 650bx2.3" Nimbus Sport Reflective tires provide excellent traction, stability, and cushioning, which creates a safer, more reliable, and more comfortable ride on either paved or dirt roads. These tires will also increase your visibility to motorists in low-light conditions.
Equipped with our Body Geometry The Cup saddle, you can expect a supreme level of comfort anywhere you take the Roll. It delivers on these expectations by "cupping" your sit bones, which reduces pressure without feeling obtrusive or constraining.
A spring suspension seatpost takes the sting out of rough terrain, giving you an extra bit of "cushion" that'll have you riding longer and more comfortably.
Technical Specifications
FRAMESET
FRAME
Specialized A1 Premium Aluminum, Ground Control Positioning, formed tubes, disc mount, fender/rack mounts
SEAT BINDER
Alloy, QR, 31.8mm
SUSPENSION
FORK
Roll Disc Steel, fender/rack mounts
WHEELS
RIMS
650b disc, double-wall aluminum, 15.5mm rim depth, 30mm internal width, 32h
FRONT HUB
Specialized disc, double-sealed, loose ball bearings, 9mm QR
REAR HUB
Specialized disc, loose ball bearings, QR
SPOKES
Stainless, 14g
FRONT TIRE
Nimbus Sport, 60 TPI, BlackBelt protection, 650b x 2.3""
REAR TIRE
Nimbus Sport, 60 TPI, BlackBelt protection, 650b x 2.3""
DRIVETRAIN
FRONT DERAILLEUR
Shimano Tourney, top swing, 31.8mm band clamp
REAR DERAILLEUR
Shimano Tourney, 7-speed
SHIFT LEVERS
Shimano EF51, EZ Fire Plus, 7-speed
CASSETTE
Shimano Tourney freewheel, 7-speed, 14-34t
CHAIN
KMC Z51, 7-speed
CRANKSET
Stout, forged alloy
CHAINRINGS
48/38/28T w/chainguard
BOTTOM BRACKET
BSA, square taper, cartridge bearings
COCKPIT
STEM
Forged alloy, 17-degree rise, 31.8mm clamp
HANDLEBARS
Specialized Roll, 6061 alloy, 15-degree backsweep, 5-degree upsweep, 125mm rise, 31.8mm
SADDLE
Body Geometry The Cup, steel rails, 245mm
SEATPOST
Dual-Bolt Diecast Head, AL6061 Post, Spring Suspension
BRAKES
FRONT BRAKE
Tektro, mechanical disc, resin pads, 160mm rotor
REAR BRAKE
Tektro, mechanical disc, resin pads, 160mm rotor
ACCESSORIES
PEDALS
Specialized City platform
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| SM | MD | LG | |
|---|---|---|---|
| Crank Length | 165mm | 170mm | 175mm |
| Handlebar Width | 680mm | 680mm | 680mm |
| Stem Length | 60mm | 60mm | 60mm |
| Saddle Width | 245mm | 245mm | 245mm |
| Seatpost Length | 350mm | 350mm | 350mm |
| Seat-Tube Angle | 67° | 67° | 67° |
| Head-Tube Length | 155mm | 185mm | 215mm |
| Head-Tube Angle | 68° | 69° | 69° |
| Chain-Stay Length | 480mm | 480mm | 480mm |
| Front-Center | 618mm | 626mm | 654mm |
| B-B Drop | 70mm | 70mm | 70mm |
| B-B Height | 285mm | 285mm | 285mm |
| Bike Stand-Over Height | 702.2mm | 764.3mm | 806mm |
| Fork Length (full) | 420mm | 420mm | 420mm |
| Top-Tube Length (horizontal) | 595mm | 615mm | 645mm |
| Seat-Tube Length | 375mm | 440mm | 480mm |
| Stack | 586mm | 619mm | 647mm |
| Reach | 346mm | 352mm | 370mm |
| Trail | 84mm | 77mm | 77mm |
| Fork Rake/Offset | 55mm | 55mm | 55mm |
| Wheelbase | 1089mm | 1097mm | 1126mm |
Manual Downloads
For safety warning please refer to the documentation in the Manual Downloads section of this page.
