Better performance. Better value. Better Rockhopper. By tapping the fit and handling…
Better performance. Better value. Better Rockhopper. By tapping the fit and handling advantages of pairing each rider with their ideal wheel size and suspension that works its hardest for everyone thanks to our size-specific Rx Tune, we’ve baked in added performance to the all-new Rockhopper without dialing up the price.
Shimano and MicroSHIFT team up for drivetrain duties with a robust 2x8 drivetrain that can handle everything you’re throw down while confident braking from Radius CX7 mechanical disc brakes seals the deal of the century.
A heart of gold, presented in our lightweight yet durable Premium A1 Aluminum, the Rockhopper features butted aluminum tubes in order to keep weight low and strength high, all while providing increased standover clearance, slick internal cable routing and dropper-post compatibility. With the goal of making sure that the Rockhopper offers both the best fit and best performance for every person, no matter their measure, we’ve paired each Rockhopper frame size with the optimal wheel size. The result is a Rockhopper to fit every rider and the assurance that every Rockhopper is rolling on the best-handling wheel for its frame size.
With Rx Tune on Rockhopper, the SR Suntour XCE brings size-specific travel and spring rates to the show in a performance that’s sure to impress while also ensuring consistent geometry, handling and suspension performance, regardless of frame size.
Radius CX-7 disc brakes offer confident, consistent braking in any trail condition.
A durable Formula freehub and SunRace 8-speed cassette keep you rolling smoothly without putting up a fuss.
Rims
Specialized alloy, disc only, double-wall, 25mm inner width, 32h
Front Hub
Formula 6-Bolt, disc, 100x9mm spacing, quick-release, 32H
Spokes
Stainless, 14g
Rear Hub
Formula SP-2125, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Inner Tubes
Schrader, 40mm valve
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Saddle
Bridge Sport, Steel rails, 155/143mm
Grips
Specialized Trail Grips, lock-on
Front Derailleur
Shimano Altus FD-M315
Shift Levers
microSHIFT, TS39-8R, 2x8-speed
Rear Derailleur
Shimano Tourney RD-TX800, 8-speed
Chain
KMC X8 EPT, anti-rust coating, 8-speed w/ reusable Missing Link™
Cassette
SunRace, 8-speed, 11-34t
Crankset
Stout 2x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Fork
SR Suntour XCE 27.5, 28mm stanchions, Rx Tune, coil spring, QR, 80/90/100mm travel (size-specific), 42mm offset
Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder
Alloy, quick release, 34.9
Front Brake
Radius CX7, mechanical disc, 160mm
Rear Brake
Radius CX7, mechanical disc, 160mm
Pedals
Specialized Body Geometry Fitness, platform, plastic
Front Tire
Ground Control Sport, 27.5x2.3"
Rear Tire
Ground Control Sport, 27.5x2.3"
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
XS | S | M | |
---|---|---|---|
Crank Length | 165mm | 170mm | 170mm |
Handlebar Width | 700mm | 720mm | 740mm |
Stem Length | 35mm | 45mm | 60mm |
Saddle Width | 155mm | 155mm | 143mm |
Seatpost Length | 300mm | 350mm | 400mm |
Stack | 559mm | 573mm | 589mm |
Reach | 375mm | 395mm | 415mm |
Head-Tube Length | 95mm | 100mm | 105mm |
Head-Tube Angle | 68° | 68° | 68° |
B-B Height | 310mm | 310mm | 310mm |
B-B Drop | 43mm | 43mm | 43mm |
Trail | 97mm | 97mm | 97mm |
Fork Length (full) | 475mm | 485mm | 495mm |
Fork Rake/Offset | 42mm | 42mm | 42mm |
Front-Center | 630mm | 656mm | 682mm |
Chain-Stay Length | 440mm | 440mm | 440mm |
Wheelbase | 1067mm | 1092mm | 1118mm |
Top-Tube Length (horizontal) | 541mm | 565mm | 589mm |
Bike Stand-Over Height | 658mm | 695mm | 735mm |
Seat-Tube Length | 310mm | 350mm | 400mm |
Seat-Tube Angle | 73.5° | 73.5° | 73.5° |
