2009 Rockhopper Comp Disc
0 Reviews
FOR OVER TWO DECADES the Rockhopper has been the best hardtail for any rider looking…
Product Details
FOR OVER TWO DECADES the Rockhopper has been the best hardtail for any rider looking for thrills and adventure over a wide variety of terrain. The Rockhopper's M4 alloy frame and premium specs deliver category-leading efficiency, value and dependable handling.
The Rockhopper Comp Disc’s M4 manipulated alloy frame is fully butted, with an ORE down tube for added strength and off-road accuracy.
The suspension fork features 100mm of smooth coil-sprung travel, rebound and preload adjustments, plus lockout—making this fork tunable to any need.
The 3D-forged alloy stem is stiff and strong and features an oversized 31.8mm bar clamp area for a solid steering connection.
The mechanical disc brakes are easy to adjust and maintain and give superb, controllable stopping power. The levers allow for powerful (when necessary) one-finger braking.
The medium cage rear derailleur gives reliable, precise gear changes.
The 8-speed trigger shifters offer quick shifts with the flick of a finger (or thumb).
The triple-chainring crankset utilizes Shimano’s Octalink-splined BB interface for highly efficient power transfer.
The high-volume Specialized Fast Trak LK Sport 26x2.0-inch tires have a reduced knob height for lower rolling resistance, without giving up an ounce of traction.
The Specialized XC saddle features Aramid side patches that hold up to rough treatment.
Technical Specifications
FRAMESET
FRAME
Specialized M4 Manipulated Alloy frame, fully butted, ORE DT, forged dropouts w/ replaceable 98954020 hanger, disc only
HEADSET
Specialized 1-1/8"" threadless, loose ball
SEAT BINDER
Specialized alloy w/ QR, brass washer
SUSPENSION
FORK
RockShox Dart 3 SL, 100mm, preload and rebound adj. w/ LO, 13/15"": standard spring, all others: ""stiff"" spring, disc only
WHEELS
FRONT TIRE
Specialized Fast Trak LK Sport, 26x2.0"", 60TPI, wire bead
REAR TIRE
Specialized Fast Trak LK Sport, 26x2.0"", 60TPI, wire bead
INNER TUBES
Specialized schraeder valve
RIMS
Specialized RHD 26"", double wall disc, pinned w/ eyelets, 28/32h
FRONT HUB
Specialized Hi Lo, forged alloy, double sealed, ground race, 28h
REAR HUB
Specialized, forged alloy, double sealed, ground race, cassette, QR, 32h
SPOKES
1.8mm (15g) stainless
DRIVETRAIN
FRONT DERAILLEUR
Shimano Altus, 34.9mm clamp, top swing
REAR DERAILLEUR
SRAM X-5, med. cage
SHIFT LEVERS
SRAM X-4, 8-speed trigger
CASSETTE
SRAM PG-830-I8, 8-speed, 11-32t
CHAIN
KMC X8 w/ reuseable Missing Link
CRANKSET
Shimano FC-M36108, Octalink spline, replaceable rings
CHAINRINGS
42S x 32S x 22S
BOTTOM BRACKET
Shimano BB-ES25, Octalink spline, cartridge bearings, 68mm x 118mm
COCKPIT
STEM
Specialized 3D forged, 4-bolt, 7 degree rise, 31.8mm clamp
HANDLEBARS
Specialized alloy, 31.8mm, 25mm rise, 640mm wide, 8 degree back sweep, 8 degree up, 2.8mm thick
GRIPS
Specialized Enduro, dual compound Kraton, no flange, 131mm
SADDLE
Specialized XC, Body Geometry, 143mm width, front and rear bumpers
SEATPOST
Specialized alloy two bolt, micro adjust head, 30.9mm
BRAKES
FRONT BRAKE
Avid BB5, mechanical disc, caliper/adapter w/ 160mm G2 Clean Sweep rotor
REAR BRAKE
Avid BB5, mechanical disc, caliper/adapter w/ 160mm G2 Clean Sweep rotor
BRAKE LEVERS
Avid FR-5, alloy, two-finger, linear pull
ACCESSORIES
PEDALS
Steel cage, composite body, 9/16""
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 13 | 15 | 17 | 19 | 21 | 23 | |
|---|---|---|---|---|---|---|
| Bottom Bracket Height - Low Setting | 304mm | 304mm | 304mm | 304mm | 304mm | 304mm |
| Top Tube Length (Horizontal) | 545mm | 565mm | 590mm | 615mm | 640mm | 660mm |
| Head Tube Height | 100mm | 100mm | 110mm | 120mm | 140mm | 160mm |
| Head Tube Angle - Low Setting | 70° | 70° | 70° | 70° | 70° | 70° |
| Seat Tube Angle (Actual) - Low Setting | 73° | 73° | 73° | 73° | 73° | 73° |
| Top Tube Length (Actual) | 546mm | 551mm | 568mm | 590mm | 615mm | 638mm |
| Seat Tube Length - Center to Top | 330mm | 381mm | 432mm | 483mm | 533mm | 584mm |
| Wheel Base | 1030mm | 1050mm | 1075mm | 1101mm | 1127mm | 1148mm |
| Standover Height | 681mm | 715mm | 750mm | 783mm | 820mm | 855mm |
| Chainstay Length | 426mm | 426mm | 426mm | 426mm | 426mm | 426mm |
| Crank Length | 170mm | 170mm | 175mm | 175mm | 175mm | 175mm |
| Handlebar Width | 640mm | 640mm | 640mm | 640mm | 640mm | 640mm |
| Stem Length | 60mm | 60mm | 75mm | 75mm | 90mm | 90mm |
| Seatpost Length | 350mm | 350mm | 350mm | 400mm | 400mm | 400mm |
