That spot where the bike path turns from concrete to dirt? The Pitch Sport is made…
That spot where the bike path turns from concrete to dirt? The Pitch Sport is made to explore beyond, with a sturdy aluminum frame, smooth-riding front suspension, grippy tires for loose surfaces, and sure-stopping hydraulic disc brakes to keep you under control.
STRONG, SENSITIVE TYPE
Old-school strongmen have nothing on our A1 Premium Aluminum frame. But the Pitch Sport is in touch with its feelings too, offering a ride that's as comfortable as it is durable, thanks to a lightweight proprietary alloy and Sport Trail 27.5 Geometry for sure handling.
SIZE-SPECIFIC SUSPENSION
It's not enough to offer quality suspension like the coil-sprung SR SunTour XCT 30 fork on the Pitch Sport. We also custom-design travel based on frame size to keep the geometry and ride quality consistent over all sizes. Lockout limits annoying bobbing on smooth terrain.
SWEET SPOT WHEELS
Why 27.5-inch wheels exactly, not 27 or 28? It's a happy medium which offers most of the benefits of the older 26-inch size, like light weight and agility, with those of the newer, oversize 29er version, like fast-rolling efficiency and easy roll over obstacles.
The 16-speed Shimano drivetrain gives you the right gear, anytime.
A long-lasting, rust-resistant KMC chain offers quiet, sure shifting.
Grippy Ground Control Sport tires feature Flak Jacket flat protection.
The heart of the Pitch Sport is the Sport Trail 27.5 Geometry, which features a roomy cockpit to keep your center of gravity securely between the wheels for control, and a slacker head angle designed for more stable steering.
The key to mountain biking is confidence, which starts with knowing you’re in control. Thanks to the Shimano hydraulic disc brakes on the Pitch Sport, you’ll always know you have plenty of stopping power, no matter the trail conditions.
We obsess about tires a little. OK, a lot, it’s where the bike meets the trail, after all. So for the Pitch line, we chose our wide, 2.3-inch Ground Control Sport, with a versatile, fast-rolling knobby tread that offers superb grip and traction for any trail.
FRAME
A1 Premium Aluminum, Sport Trail 27.5 Geometry, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger
SEAT BINDER
Alloy, QR clamp, 34.9mm
FORK
SR SunTour XCT 30 w/ MCD lock out, Rx Tune, coil spring, 42mm offset, 80/90/100mm of travel of (size-specific)
STEM
Stout 3D-forged alloy, 31.8mm, 6-degree rise
HANDLEBARS
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
GRIPS
Specialized MTB Grip, lock-on
SEATPOST
Alloy, 12mm offset, 2-bolt clamp, 30.9mm
FRONT BRAKE
Shimano BR-MT200, hydraulic disc, 160/180mm
REAR BRAKE
Shimano BR-MT200, hydraulic disc, 160mm
FRONT DERAILLEUR
Shimano Altus FD-M315
REAR DERAILLEUR
Shimano Acera, 8-speed
SHIFT LEVERS
Shimano EF505, hydraulic, 8-speed
CASSETTE
Sunrace, 8-speed, 11-34t
CHAIN
KMC X8 EPT, anti-rust coating, 8-speed w/ reusable Missing Link™
CRANKSET
Stout 2x, forged alloy
CHAINRINGS
36/22T
BOTTOM BRACKET
Square-tapered, 73mm, internal bearings
RIMS
Stout Trail 27.5, alloy, disc-specific, double-wall, 25mm internal width, 32h
FRONT HUB
Shimano, Center Lock™ disc, 9x100mm spacing, quick-release, 32h
REAR HUB
Shimano FH-TX505, Center Lock™ disc, 9x135mm spacing, quick-release, 32h
SPOKES
Stainless, 14g
FRONT TIRE
Ground Control Sport, 60 TPI, wire bead, Flak Jacket Flat protection, 27.5 x 2.3"
REAR TIRE
Ground Control Sport, 60 TPI, wire bead, Flak Jacket Flat protection, 27.5 x 2.3"
INNER TUBES
Schrader valve
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
XS | S | M | L | XL | |
---|---|---|---|---|---|
Crank Length | 165 | 170 | 170 | 175 | 175 |
Handlebar Width | 720mm | 720mm | 740mm | 740mm | 740mm |
Stem Length | 35 | 45 | 45 | 60 | 60 |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 350 | 350 | 350 | 400 | 400 |
Stack | 562mm | 562mm | 585mm | 604mm | 618mm |
Reach | 380mm | 400mm | 420mm | 440mm | 460mm |
Head Tube Length | 95mm | 95mm | 100mm | 120mm | 135mm |
Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
BB Height | 310mm | 310mm | 310mm | 310mm | 310mm |
BB Drop | 43mm | 43mm | 43mm | 43mm | 43mm |
Trail | 94mm | 94mm | 94mm | 94mm | 94mm |
Fork Length, Full | 475mm | 475mm | 495mm | 495mm | 495mm |
Fork Rake/Offset | 42mm | 42mm | 42mm | 42mm | 42mm |
Front Center | 631mm | 651mm | 680mm | 708mm | 733mm |
Chainstay Length | 435mm | 435mm | 435mm | 435mm | 435mm |
Wheelbase | 1063mm | 1083mm | 1112mm | 1139mm | 1165mm |
Top Tube Length, Horizontal | 542mm | 572mm | 599mm | 625mm | 649mm |
Bike Standover Height | 660mm | 690mm | 739mm | 766mm | 808mm |
Seat Tube Length | 310mm | 360mm | 415mm | 450mm | 510mm |
Seat Tube Angle | 74° | 73° | 73° | 73° | 73° |
