2009 P.1
0 Reviews
P. BIKES ARE A LIFESTYLE, born and bred with the integrity to push the limits of…
Product Details
P. BIKES ARE A LIFESTYLE, born and bred with the integrity to push the limits of physics at your favorite jumps, streets and skate parks. All-over cold forgings, super short chainstays, high-riser jump bars and short extension stems make P. bikes durable and nimble enough to keep you moving up, not breaking down.
100% Cr-Mo, disc-only frame featuring stiff and strong double-butted top/down tubes, an externally relieved head tube and hardware for single or multi-speed setups.
The 80mm-travel Marzocchi DJ3 fork features oversized 32mm Cr-Mo stanchions, magnesium lowers and a plush, but stiff coil/mcu spring for high-performance.
Specialized 3D-forged Aggro stem is stiff and tough and accepts a 31.8mm diameter alloy riser bar: 680mm width and 8-degree back/upsweep for perfect positioning.
Avid BB5 mechanical disc brakes ensure smooth, reliable stops with an 160mm G2 Clean Sweep rotor in front and 140mm rotor in back.
Fuse tubular two-piece Cr-Mo cranks are stiff and durable, and combined with the 28-tooth Motostar chainring and Fuse Euro cartridge- bearing BB, you get a smooth spinning, reliable drivetrain, no matter what.
26x2.3-inch Rhythm Lite Control tires have a dual compound tread that rolls fast in the transition, with extra grip on the shoulders for precise cornering in the dirt.
The Fuse Lo Pro saddle is designed for comfort, ease of movement and strength for hard landings.
Technical Specifications
FRAMESET
FRAME
Specialized 100% Cr-Mo, double-butted HT/DT, externally relieved HT, disc mount, 6mm offset horizontal drop out for 26"" wheel w/ single- and multispeed hardware, disc only
HEADSET
Tank FX, 1-1/8"" threadless w/ hollow bolt
SEAT BINDER
Integrated w/ replaceable single bolt
SUSPENSION
FORK
Marzocchi DJ3, 80mm, Cr-Mo steerer, 32mm Cr-Mo stanchions, magnesium lower, fixed rate catridge damping, coil/mcu w/ preload adj., ""stiff"" spring
WHEELS
RIMS
Specialized/Alex P.Disc AM, double wall disc w/ eyelets, 36h
FRONT HUB
Specialized, forged alloy, high/low flange, 36h, nutted 3/8"" axle
REAR HUB
Specialized Hi Lo, forged alloy, double sealed, ground race, cassette, nutted with 3/8"" axle, 36h
SPOKES
1.8mm (15g) stainless
FRONT TIRE
Specialized Rhythm Control, 26x2.3"", 60TPI, aramid bead
REAR TIRE
Specialized Rhythm Control, 26x2.3"", 60TPI, aramid bead
INNER TUBES
Specialized schraeder valve
DRIVETRAIN
CASSETTE
Joy Tech, 2 alloy spacers w/ 1/2"" x 1/8"" x 14t Cr-Mo cog
CHAIN
KMC Z510HX, 1/2"" x 1/8""
CRANKSET
Fuse tubular heat treated Cr-Mo 3pc.
CHAINRINGS
CNC cut 6061, 28t, Motostar design
BOTTOM BRACKET
Fuse Euro, alloy cups, 4x cartridge bearing
COCKPIT
STEM
Specialized aggro, 3D forged/CNC, 4-bolt, 35mm length
HANDLEBARS
Specialized alloy riser bar, 31.8mm, 55mm rise, 680mm wide, 8 degree back sweep, 8 degree up
GRIPS
Fuse BMX, single compound, closed end, 140mm
SADDLE
Specialized Fuse Lo Pro, 8mm rails, PVC bumpers front and rear
SEATPOST
Specialized alloy two bolt, no offset, micro adjust, 30.9mm
BRAKES
FRONT BRAKE
Avid BB5, mechanical disc, caliper/adapter w/ 160mm G2 Clean Sweep rotor
REAR BRAKE
Avid BB5, mechanical disc, caliper/adapter w/ 140mm G2 Clean Sweep rotor
BRAKE LEVERS
Avid FR-5, alloy, two-finger, linear pull
ACCESSORIES
PEDALS
Specialized alloy platform, 9/16""
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| L | |
|---|---|
| Bottom Bracket Height - Low Setting | 300mm |
| Top Tube Length (Horizontal) | 595mm |
| Head Tube Height | 110mm |
| Head Tube Angle - Low Setting | 68.5° |
| Seat Tube Angle (Actual) - Low Setting | 71° |
| Top Tube Length (Actual) | 568mm |
| Seat Tube Length - Center to Top | 348mm |
| Wheel Base | 1052mm |
| Standover Height | 711mm |
| Chainstay Length | 392mm |
| Crank Length | 175mm |
| Handlebar Width | 640mm |
| Stem Length | 40mm |
| Seatpost Length | 300mm |
