2015 Jett Sport
5
1 Reviews
Jett provides the smooth ride and improved handling of 29" wheels in an A1 aluminum…
Color:
Gloss Black/White/Charcoal
What's my size?
Select a Size
Product Details
Jett provides the smooth ride and improved handling of 29" wheels in an A1 aluminum XC trail bike for women. The Jett Sport features Women's XC 29er Geometry, custom-tuned SR Suntour XCM 29 fork, and Tektro Auriga hydraulic disc brakes with women's short-reach levers for precise braking.
Women's Body Geometry XC Contour, lock-on grips provide slip-free bar control
Specialized Stout, 9-speed crankset for efficient and precise shifting
Custom SR Suntour XCM 80mm-travel fork w/ exclusive Multi-Circuit Damping
Shimano Acera, 9-speed rear derailleur for reliable, crisp shifting
Body Geometry Women's Riva Sport Plus saddle features generous padding for all-day comfort
A1 Premium Aluminum frame w/ Women's XC 29er Geometry is confidence-inspiring and efficient
Tektro Auriga, hydraulic disc brakes w/ women's short-reach levers for maximum stopping power
Technical Specifications
FRAMESET
FRAME
Specialized A1 Premium Aluminum, Women's XC 29er Geometry, women's butted tubesets, forged post-mount 160mm dropouts, replaceable derailleur hanger, kickstand mount
HEADSET
1-1/8"" upper/lower, Zerostack 44, steel cups, loose ball bearings
SEAT BINDER
Alloy, nylon/glass fiber washer, QR, 34.9mm
SUSPENSION
FORK
Custom SR Suntour XCM 29, w/ custom Multi-Circuit Damping, alloy lowers, custom women's coil/MCU spring weights, Hi-Ten 30mm stanchions, 1-1/8"" steerer, hydraulic lockout w/ preload adjust, disc mount, 80mm travel
WHEELS
RIMS
Specialized Stout, 29"" disc, alloy double-wall, pin joint, 25mm inner width, 32h
FRONT HUB
Specialized Hi Lo disc, alloy double-sealed, ground race, QR, 32h
REAR HUB
Specialized Hi Lo disc, alloy, double-sealed, loose ball bearings, QR, 32h
SPOKES
Stainless, 14g, w/ brass nipple
FRONT TIRE
Specialized Ground Control Sport, 60TPI, wire bead, 29x2.1""
REAR TIRE
Specialized Ground Control Sport, 60TPI, wire bead, 29x2.1""
INNER TUBES
Standard, Schrader valve
DRIVETRAIN
FRONT DERAILLEUR
Shimano Altus, high mount, bottom swing, dual-pull
REAR DERAILLEUR
Shimano Acera, 9-speed, SGS cage
SHIFT LEVERS
Shimano Altus Rapidfire Plus, SL type, w/ optical display
CASSETTE
Sunrace, 9-speed, 11-34
CHAIN
KMC X9, 9-speed, reusable Missing Link
CRANKSET
Specialized Stout, forged alloy, 9-speed, square taper spindle
BOTTOM BRACKET
Square taper, cartridge bearings
COCKPIT
STEM
Specialized 3D forged alloy, 4-bolt, 6-degree rise
HANDLEBARS
Specialized flat, 6061 double butted alloy, 10-degree backsweep, 4-degree upsweep, 31.8mm
GRIPS
Specialized Body Geometry XCT Women's, Kraton w/ gel, lock-on, closed end, 121.5mm
SADDLE
Body Geometry Women's Riva Sport Plus, steel rails, 155mm
SEATPOST
Alloy, 2-bolt, micro-adjust, 12.5mm offset, 27.2mm, anti-corrosion hardware
BRAKES
FRONT BRAKE
Tektro Auriga, hydraulic disc, resin/metallic pads, tooled women's reach adjust
REAR BRAKE
Tektro Auriga, hydraulic disc, resin/metallic pads, tooled women's reach adjust
BRAKE LEVERS
Tektro Auriga, hydraulic, women's short reach
ACCESSORIES
PEDALS
Composite platform, w/ reflectors, 9/16""
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| SM | MD | LG | |
|---|---|---|---|
| Top Tube Length (Horizontal) | 559mm | 577mm | 601mm |
| Top Tube Length (Actual) | 547mm | 555mm | 573mm |
| Seat Tube Length, Center to Top | 361mm | 417mm | 468mm |
| Bottom Bracket Drop | 64.5mm | 64.5mm | 64.5mm |
| Bottom Bracket Height | 308mm | 308mm | 308mm |
| Wheel Base | 1071mm | 1084mm | 1109mm |
| Standover Height | 684mm | 725mm | 754mm |
| Stack | 612mm | 623mm | 633mm |
| Reach | 378mm | 392mm | 414mm |
| Head Tube Length | 100mm | 110mm | 120mm |
| Head Tube Angle | 70° | 70.5° | 70.5° |
| Front Center | 629mm | 642mm | 667mm |
| Chainstay Length | 450mm | 450mm | 450mm |
| Seat Tube Angle | 73.5° | 73.5° | 73.5° |
| Crank Length | 170mm | 170mm | 175mm |
| Handlebar Width | 660mm | 660mm | 660mm |
| Stem Length | 60mm | 80mm | 80mm |
| Seatpost Length | 350mm | 350mm | 350mm |
Manual Downloads
For safety warning please refer to the documentation in the Manual Downloads section of this page.
