2010 Haul 2
0 Reviews
Riders who would rather use their legs than drive a car will love this real-deal…
Product Details
Riders who would rather use their legs than drive a car will love this real-deal cargo bike with integrated deck, lights and fenders. The HAUL is designed for carrying heavier loads than you thought possible on two wheels.
Folding alloy kickstand
Disc-brake compatible aluminum fork is light and durable
LED front and rear lights included for visibility and safety
Globe City grips deliver form, fit and function in one simple design
Slim and effective color-matched alloy chainguard keeps your duds clean
Beautiful Elm wood deck adds to the function of the rear rack - holds 40kg
Globe classic aluminum fenders are color matched with custom chevron detail
Wheels feature double-walled 700c rims with 36 spokes for maximum durability
Mechanical disc brakes supply strong, consistent stopping power in any situation
Shimano Alfine 8-speed internal hub is the epitome of quality, versatility and simplicity
Body Geometry Sonoma saddle uses a V-groove design and vibration dampers for comfort and support, even on dodgy roads
Globe A1 Premium Aluminum frame with custom tubing and butting profiles, sturdy integrated rack makes loaded transport simple, secure and easy
Technical Specifications
FRAMESET
FRAME
Globe A1 Premium Aluminum cargo design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount, fully integreated rear rack w/ forged dropout and pannier hook
FORK
Globe Haul straight-blade steel fork
HEADSET
1-1/8"" threadless, integrated, semi-cartridge campy style bearings
SEAT BINDER
Globe Chevron forged alloy, chrome plated
WHEELS
FRONT HUB
Hi Lo flange, machined disc mount, loose ball, QR, 36h
REAR HUB
Shimano Alfine internal 8-speed, 36h
SPOKES
1.8mm (15g) stainless
FRONT TIRE
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
REAR TIRE
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
INNER TUBES
Schraeder valve
RIMS
Globe 700c, double wall, 36h w/ eyelets
DRIVETRAIN
SHIFT LEVERS
Shimano Alfine tape fire, 8-speed
CRANKSET
Sugino EX-1 aluminum, w/ alloy chainguard
CHAINRINGS
38t w/ chainguard
CASSETTE
Shimano Alfine single cog
BOTTOM BRACKET
Cartridge bearing, square spindle with crank stop right side and capless bolts
CHAIN
KMC 1/2x1/8""
COCKPIT
SADDLE
Specialized BG Sonoma, 155mm width
TAPE
Globe City 140mm
SEATPOST
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
HANDLEBARS
Alloy, 31.8mm, 650mm wide, 31 degree up, 24 degree back sweep
STEM
Forged alloy, 4-bolt, 31.8mm, 8 degree rise, including LED top-cap light
BRAKES
FRONT BRAKE
Tektro Novela, mechanical disc
REAR BRAKE
Tektro Novela, mechanical disc
BRAKE LEVERS
Two finger lever
ACCESSORIES
PEDALS
Globe City, Body Geometry, composite w/rubber top, 1.5mm varus wedge
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| SM | MD | LG | XL | |
|---|---|---|---|---|
| Seat-Tube Angle | 74.5° | 74° | 73.5° | 73° |
| Head-Tube Length | 140mm | 170mm | 200mm | 230mm |
| Seat-Post Length | 0mm | 0mm | 0mm | 0mm |
| Head-Tube Angle | 69.5° | 69.5° | 70° | 70.5° |
| Chain-Stay Length | 500mm | 500mm | 500mm | 500mm |
| Top-Tube Length, Horizontal | 550mm | 565mm | 580mm | 595mm |
| Front-Center | 638mm | 650mm | 656mm | 661mm |
| Stand-Over Height | 711mm | 747mm | 773mm | 818mm |
| Seat-Tube Length, B-B Center to Top | 385mm | 435mm | 460mm | 510mm |
| Fork Rake | 51mm | 51mm | 51mm | 51mm |
| B-B Drop | 65mm | 65mm | 65mm | 65mm |
| Trail | 78mm | 78mm | 74mm | 71mm |
| Wheelbase | 1131mm | 1143mm | 1149mm | 1154mm |
