2010 Haul 2 Step Through
5
1 Reviews
Riders who would rather use their legs than drive a car will love this real-deal…
Product Details
Riders who would rather use their legs than drive a car will love this real-deal cargo bike with integrated deck, lights and fenders. The HAUL is designed for carrying heavier loads than you thought possible on two wheels.
Folding kickstand
Integrated rack and wood deck - holds 40kg
Disc-brake compatible aluminum fork is simple, light and durable
Globe City grips deliver form, fit and function in one simple design
Slim and effective color-matched alloy chainguard keeps your duds clean
Body Geometry Sonoma saddle uses a V-groove design for comfort and support
Wheels feature double-walled 700c rims with 36 spokes for maximum durability
Shimano Alfine 8-speed internal hub is the epitome of quality, versatility and simplicity
Natural-finish Globe alloy fenders are a more durable alternative to the typical plastic variety
Globe A1 Premium Aluminum step-through frame with integrated rack makes loaded transportation simple and easy
Technical Specifications
FRAMESET
FRAME
Globe A1 Premium Aluminum cargo design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount, fully integrated rear rack w/ forged dropout and pannier hook
FORK
Globe Haul straight-blade steel fork
HEADSET
1-1/8"" threadless, integrated, semi-cartridge campy style bearings
SEAT BINDER
Globe Chevron forged alloy, chrome plated
WHEELS
FRONT HUB
Hi Lo flange, machined disc mount, loose ball, QR, 36h
REAR HUB
Shimano Alfine internal 8-speed, 36h
SPOKES
1.8mm (15g) stainless
FRONT TIRE
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
REAR TIRE
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
INNER TUBES
Schraeder valve
RIMS
Globe 700c, double wall, 36h w/ eyelets
DRIVETRAIN
CASSETTE
Shimano Alfine single cog
SHIFT LEVERS
Shimano Alfine tap fire, 8-speed
BOTTOM BRACKET
Cartridge bearing, square spindle with crank stop right side and capless bolts
CHAIN
KMC 1/2x1/8""
CRANKSET
Sugino EX-1 aluminum, w/ alloy chainguard
CHAINRINGS
38t w/ chainguard
COCKPIT
TAPE
Globe City 140mm
SEATPOST
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
HANDLEBARS
Alloy, 31.8mm, 650mm wide, 31 degree up, 24 degree back sweep
STEM
Forged alloy, 4-bolt, 31.8mm, 8 degree rise, including LED top-cap light
SADDLE
Specialized BG Sonoma women's, 157mm width
BRAKES
FRONT BRAKE
Tektro Novela, mechanical disc
REAR BRAKE
Tektro Novela, mechanical disc
BRAKE LEVERS
Two-finger mechanical lever
ACCESSORIES
PEDALS
Globe City, Body Geometry, composite w/rubber top, 1.5mm varus wedge
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| SM | MD | LG | |
|---|---|---|---|
| Seat-Tube Angle | 74.5° | 74° | 73.5° |
| Head-Tube Length | 140mm | 170mm | 200mm |
| Seat-Post Length | 0mm | 0mm | 0mm |
| Head-Tube Angle | 69.5° | 69.5° | 70° |
| Chain-Stay Length | 500mm | 500mm | 500mm |
| Top-Tube Length, Horizontal | 540mm | 555mm | 570mm |
| Front-Center | 628mm | 640mm | 646mm |
| Stand-Over Height | 603mm | 612mm | 617mm |
| Seat-Tube Length, B-B Center to Top | 385mm | 435mm | 460mm |
| Fork Rake | 51mm | 51mm | 51mm |
| B-B Drop | 65mm | 65mm | 65mm |
| Trail | 78mm | 78mm | 74mm |
| Wheelbase | 1121mm | 1133mm | 1139mm |
