2010 Haul 1
0 Reviews
Riders who would rather use their legs than drive a car will love this real-deal…
Product Details
Riders who would rather use their legs than drive a car will love this real-deal cargo bike with integrated deck, lights and fenders. The HAUL is designed for carrying heavier loads than you thought possible on two wheels.
Folding alloy kickstand
Globe City grips deliver form, fit and function in one simple design
Slim and effective color-matched alloy chainguard keeps your duds clean
Beautiful Elm wood deck adds to the function of the rear rack - holds 40kg
Globe classic aluminum fenders are color matched with custom chevron detail
Shimano Alivio 8-speed rear derailleur and double front crank are tough and precise
Body Geometry Fitness saddle with front and rear bumpers for comfort where it counts
Double-walled 700c rims with machined sidewalls offer durability in a lightweight profile
Form-fit LED tail light with steady and flashing functions, front light integrated into handlebar stem for visibility
Globe A1 Premium Aluminum frame with custom tubing and butting profiles, sturdy integrated rack makes loaded transport simple, secure and easy
Technical Specifications
FRAMESET
FRAME
Globe A1 Premium Aluminum cargo design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount, fully integrated rear rack w/ forged dropout and pannier hook
FORK
Globe Haul straight-blade steel fork
HEADSET
1-1/8"" threadless, integrated, semi-cartridge campy style bearings
SEAT BINDER
Globe Chevron forged alloy, chrome plated
WHEELS
REAR HUB
Forged alloy, double sealed, ground race, cassette, QR, 36h
SPOKES
1.8mm (15g) stainless
FRONT TIRE
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
REAR TIRE
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
INNER TUBES
Schraeder valve
RIMS
Globe 700c, double wall, 36h w/CNC side wall
FRONT HUB
Forged alloy, double sealed, ground race, QR, 36h
DRIVETRAIN
FRONT DERAILLEUR
Shimano FD-M310, 31.8mm clamp, top swing, dual pull
REAR DERAILLEUR
Shimano Alivio, 8-speed
SHIFT LEVERS
Shimano SL-MC40, 8-speed, Rapid Fire
CASSETTE
SRAM PG-820, 8-speed, 11-32t
CHAIN
KMC Z8, w/ reusable Missing Link
CRANKSET
FSA alloy crank arm
CHAINRINGS
38 x 28S w/ alloy guard
BOTTOM BRACKET
Cartridge bearing, square spindle with crank stop right side and capless bolts
COCKPIT
STEM
Forged alloy, 4-bolt, 31.8mm, 8 degree rise, including LED top-cap light
HANDLEBARS
Alloy, 31.8mm, 650mm wide, 31 degree up, 24 degree back sweep
TAPE
Globe City 140mm
SADDLE
Specialized Body Geometry Fitness, 143mm width, front and rear bumpers
SEATPOST
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
BRAKES
FRONT BRAKE
Alloy linear pull, 1pc. pad
REAR BRAKE
Alloy linear pull, 1pc. pad
BRAKE LEVERS
V-Brake, linear pull
ACCESSORIES
PEDALS
Globe City, Body Geometry, composite w/rubber top, 1.5mm varus wedge
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| SM | MD | LG | XL | |
|---|---|---|---|---|
| Seat-Tube Angle | 74.5° | 74° | 73.5° | 73° |
| Head-Tube Length | 140mm | 170mm | 200mm | 230mm |
| Seat-Post Length | 0mm | 0mm | 0mm | 0mm |
| Head-Tube Angle | 69.5° | 69.5° | 70° | 70.5° |
| Chain-Stay Length | 500mm | 500mm | 500mm | 500mm |
| Top-Tube Length, Horizontal | 550mm | 565mm | 580mm | 595mm |
| Front-Center | 638mm | 650mm | 656mm | 661mm |
| Stand-Over Height | 711mm | 747mm | 773mm | 818mm |
| Seat-Tube Length, B-B Center to Top | 385mm | 435mm | 460mm | 510mm |
| Fork Rake | 51mm | 51mm | 51mm | 51mm |
| B-B Drop | 65mm | 65mm | 65mm | 65mm |
| Trail | 78mm | 78mm | 74mm | 71mm |
| Wheelbase | 1131mm | 1143mm | 1149mm | 1154mm |
