2015 Hardrock 26
5
3 Reviews
The Hardrock is prepared for mountain trails and urban jungles, with a smooth SR…
Product Details
The Hardrock is prepared for mountain trails and urban jungles, with a smooth SR Suntour fork, plus lightweight V-brakes, and reliable Shimano 7-speed drivetrain.
Lightweight die-cast V-Brakes for reliable stopping performance
Shimano 7-speed derailleur for reliable shifting performance
Specialized Body Geometry mountain saddle is tuned for trail performance and reduced fatigue
Specialized Fast Trak Sport 2.0" tires w/ a race-proven tread
75mm-travel SR Suntour fork delivers a plush ride for varying terrain
A1 Premium Aluminum frame with ORE downtube for a lighter, more compliant and durable bike
Efficient and precise 9-speed crankset
Technical Specifications
FRAMESET
FRAME
Specialized A1 Premium Aluminum, ORE downtube, externally relieved headtube, forged dropouts w/ reinforced disc mount, replaceable alloy derailleur hanger
HEADSET
1-1/8"" threadless, loose ball
SEAT BINDER
Alloy, nylon/glass fiber washer, QR, 34.9mm
SUSPENSION
FORK
SR Suntour M3030, alloy lowers, custom coil/MCU spring weights, Hi-Ten 25.4mm stanchions, 1-1/8"" steerer, preload adjust, V-brake mount, 75mm travel
WHEELS
RIMS
26"" V-brake, alloy double-wall, CNC sidewalls, pin joint, 25mm wide, 32h
FRONT HUB
Double-sealed, loose ball bearings, QR, 32h
REAR HUB
Alloy, freewheel type, sealed, loose ball bearings, QR, 32h
SPOKES
Stainless, 14g, w/ brass nipple
FRONT TIRE
Specialized Fast Trak Sport, 30TPI, wire bead, Flak Jacket protection, 26x2.0""
REAR TIRE
Specialized Fast Trak Sport, 30TPI, wire bead, Flak Jacket protection, 26x2.0""
INNER TUBES
Standard, Schrader valve
DRIVETRAIN
FRONT DERAILLEUR
Shimano Tourney, 3-speed, top swing, dual-pull
REAR DERAILLEUR
Shimano Tourney, 7-speed
SHIFT LEVERS
Shimano ST-EF51, 7-speed, trigger, w/ integrated brake lever
CASSETTE
Shimano, 7-speed, 14-34
CHAIN
KMC X8, 8-speed, reusable Missing Link
CRANKSET
Forged alloy, square taper spindle, w/ chainguard
BOTTOM BRACKET
Square taper, cartridge bearings
COCKPIT
STEM
Specialized, forged alloy, 4-bolt, 10-degree rise, anti-corrosion hardware
HANDLEBARS
Specialized riser, Hi-Ten steel, 8-degree backsweep, 4-degree upsweep, 35mm rise, 25.4mm
GRIPS
Specialized Body Geometry XCT, Kraton w/ gel, lock-on, closed end, 132mm
SADDLE
Body Geometry mountain, thick padding, steel rails, 143mm
SEATPOST
Alloy, 2-bolt, micro-adjust, 12.5mm offset, 30.9mm, anti-corrosion hardware
BRAKES
FRONT BRAKE
Die-cast alloy V-brake, 60mm pads
REAR BRAKE
Die-cast alloy V-brake, 60mm pads
ACCESSORIES
PEDALS
Composite platform, w/ reflectors, 9/16""
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Top Tube Length (Horizontal) | 540mm | 561mm | 586mm | 605mm | 630mm | 655mm |
| Top Tube Length (Actual) | 534mm | 542mm | 562mm | 581mm | 608mm | 637mm |
| Seat Tube Length, Center to Top | 330mm | 394mm | 444mm | 483mm | 533mm | 584mm |
| Bottom Bracket Drop | 41mm | 41mm | 41mm | 41mm | 41mm | 41mm |
| Bottom Bracket Height | 299mm | 299mm | 299mm | 299mm | 299mm | 299mm |
| Wheel Base | 1018mm | 1039mm | 1065mm | 1084mm | 1110mm | 1136mm |
| Standover Height | 687mm | 724mm | 760mm | 782mm | 817mm | 852mm |
| Stack | 556mm | 556mm | 575mm | 575mm | 594mm | 613mm |
| Reach | 370mm | 391mm | 410mm | 429mm | 449mm | 468mm |
| Head Tube Length | 100mm | 100mm | 120mm | 120mm | 140mm | 160mm |
| Head Tube Angle | 70.25° | 70.25° | 70.25° | 70.25° | 70.25° | 70.25° |
| Chainstay Length | 424.5mm | 424.5mm | 424.5mm | 424.5mm | 424.5mm | 424.5mm |
| Seat Tube Angle | 73° | 73° | 73° | 73° | 73° | 73° |
| Crank Length | 170mm | 170mm | 175mm | 175mm | 175mm | 175mm |
| Handlebar Width | 640mm | 640mm | 640mm | 640mm | 640mm | 640mm |
| Stem Length | 70mm | 75mm | 75mm | 90mm | 90mm | 90mm |
| Seatpost Length | 300mm | 350mm | 350mm | 400mm | 400mm | 400mm |
