2010 Epic Expert
0 Reviews
With a XC World Championship to its name and complete bike weights as low as 21.5…
Product Details
With a XC World Championship to its name and complete bike weights as low as 21.5 pounds, the Epic® is the lightest, most efficient and fastest performance cross-country bike available. An integrated approach to the design of all its critical components, along with an enhanced AFR inertia rear shock and Specialized/FOX Shox Mini Brain® damper, will no doubt make a full suspension convert out of any competition- hungry rider.
DT Swiss X420SL 24mm-wide rims are sleeved and eyeletted for a sturdy and lightweight package that makes the climb out effortless
Shimano XT 2-piece crankset promises legendary performance with a heralded strength-to-weight ratio for ample cross-country power
M5 alloy frame redefines the Competitive XC category with 100mm of supple FSR suspension, delivering small bump performance and smooth terrain efficiency
Avid Elixir R Carbon SL brakes/levers with tool-free reach adjust, alloy backed semi-metallic pads and carbon blades offer power-packed performance for speedy runs
S-Works The Captain 26 x 2.0" 2Bliss front tire works in concert with the S-Works Fast Trak LK rear tire to deliver exceptional traction, while minimizing rotating weight
Battle-tested RockShox SID Race 100mm air-sprung fork with rebound, compression, lockout adjust and FloodGate control dials in the perfect pedaling platform while retaining light weight
Specialized and Fox blend their brains to develop the new FlowControl Mini Brain shock with Brain Fade inertia valve, air spring and adjustable rebound, with travel optimized for the 29" frame
9mm thru-axle front hub with hi/lo flanges and DT Swiss Competition spokes comes with 24/28mm end caps for increased tracking strength and multi-fork compatibility, with a quality DT Swiss alloy freehub in the rear
Technical Specifications
FRAMESET
FRAME
Epic FSR M5 alloy, fully manipulated frame w/ ORE DT/TT, sealed cartridge bearings, 100mm travel, replaceable derailleur hanger
HEADSET
1-1/8"" Threadless, 10mm insertion alloy cups, sealed cartridge bearing
SEAT BINDER
7050 hard annodized alloy collar w/ QR, 34.9mm clamp ID, black
SUSPENSION
REAR SHOCK
Fox/SBC remote Mini-Brain, inertia valve, w/ Brain fade adjust
FORK
RockShox SID Race for Specialized, 100mm travel, air spring, rebound and floodgate compression adj.w/ LO, alloy steerer
WHEELS
RIMS
Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
FRONT HUB
Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, oversized 28mm end caps, 9mm DT RWS, alloy QR, 28h
REAR HUB
Custom DT Swiss 330SL w/ alloy freehub, QR, 32h
SPOKES
DT Swiss Competition 1.8/1.6mm stainless
FRONT TIRE
S-Works The Captain, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
REAR TIRE
S-Works Fast Trak LK, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
INNER TUBES
Ultralight presta valve
DRIVETRAIN
FRONT DERAILLEUR
Shimano M660 SLX, DMD, top swing, dual pull
REAR DERAILLEUR
SRAM X-0, 9-speed, mid cage
SHIFT LEVERS
SRAM X-9 aluminum trigger
CASSETTE
Shimano HG61, 9-speed, 11-34t
CHAIN
SRAM PC-971, 9-speed w/Power Link
CRANKSET
Custom Shimano FC-M762 XT, 2pc., S: 170mm, others: 175mm
CHAINRINGS
44A x 32A x 22S, 4-bolt, 104/64mm
BOTTOM BRACKET
Custom Shimano, outboard bearing
COCKPIT
SEATPOST
2014 butted alloy, single bolt setback, 30.9mm
STEM
3D forged alloy, adjustable rise, 31.8mm clamp
HANDLEBARS
Specialized XC low rise bar, 7050 butted alloy, 31.8mm, 660mm wide, 8 degree back sweep, 6 degree up
GRIPS
Specialized waffle lock on grip (S/M) Specialized Thick lock on grip (L/XL)
SADDLE
Specialized Phenom, hollow Cr-Mo rails, thin foam, S/M: 130mm, L/XL: 143mm
BRAKES
FRONT BRAKE
Custom Avid Elixir CR SL, alloy backed semi-met pads, S/M: 160mm, L/XL: 185mm rotor
REAR BRAKE
Custom Avid Elixir CR SL, alloy backed semi-met pads, S/M: 140mm, L/XL: 160mm rotor
BRAKE LEVERS
Custom Avid Elixir CR SL Hydraulic, carbon lever blade, tool-less adj. reach and pad contact
ACCESSORIES
PEDALS
None
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Ground-Top | 878mm | 898mm | 916mm | 935mm |
| Bottom Bracket Height - Low Setting | 331mm | 331mm | 331mm | 331mm |
| Top Tube Length (Horizontal) | 554mm | 589mm | 615mm | 641mm |
| Head Tube Height | 100mm | 120mm | 140mm | 160mm |
| Head Tube Angle - Low Setting | 70° | 70° | 70° | 70° |
| Seat Tube Angle (Actual) - Low Setting | 74.2° | 74.2° | 74.2° | 74.2° |
| Top Tube Length (Actual) | 548mm | 572mm | 597mm | 624mm |
| Seat Tube Length - Center to Top | 394mm | 444mm | 483mm | 533mm |
| Wheel Base | 1061mm | 1098mm | 1126mm | 1153mm |
| Standover Height | 729mm | 751mm | 759mm | 764mm |
| Stack | 547mm | 567mm | 585mm | 604mm |
| Reach | 400mm | 429mm | 450mm | 470mm |
| Chainstay Length | 425mm | 425mm | 425mm | 425mm |
| Crank Length | 170mm | 175mm | 175mm | 175mm |
| Handlebar Width | 660mm | 660mm | 660mm | 660mm |
| Stem Length | 75mm | 90mm | 105mm | 105mm |
| Seatpost Length | 350mm | 350mm | 400mm | 400mm |
