2020 Epic Expert Carbon EVO
$5,520
5
6 Reviews
Ripping around between the tape is one way to worship at the altar of speed, but…
Product Details
Ripping around between the tape is one way to worship at the altar of speed, but for all the other long, fast rides or marathon races on technical terrain, there's our all-new Epic Expert EVO.
A MORE EPIC KIND OF EPIC
Dropper posts and slightly longer forks may seem like overkill on an XC bike. We beg to differ. Epic EVOs are not only fast off the start line, they're even better suited to masochistically long rides, multi-day stage races, and fast backcountry missions.
HARDTAIL EFFICIENT. FULL-SUSPENSION CONTROL
Suspension should always make you faster—never slow you down with energy-sucking suspension bob. Our ingenious Brain-equipped shocks keep the Epic firm when the trail is smooth, then automatically turns your bike plush the moment your tires meet rocks and roots.
• Race-proven, carbon chassis and ingenious Brain suspension—nothing’s faster.
• Increased control courtesy of an ultralight and ultra-capable Fox Step-Cast 34 fork.
• SRAM GX Eagle drivetrain gives you all the gearing you need to tackle the biggest climbs.
Technical Specifications
ACCESSORIES
SWAT
SWAT EMT Cage-Mount Tool
Pedals
PEDAL, TEST RIDE PEDALS PROVIDED BY SPECIALIZED
DRIVETRAIN
Rear Derailleur
SRAM GX Eagle, 12-speed
Cassette
SRAM XG-1275 Eagle, 12-speed, 10-50t
Shift Levers
SRAM GX Eagle, trigger, 12-speed
Chain
SRAM NX Eagle, 12-speed
Crankset
Truvativ STYLO, DUB
Chainrings
Steel, 30T
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
FRAMESET
Frame
Specialized FACT 11m, XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 100mm of travel
Seat Binder
Specialized Alloy, 34.9mm
BRAKES
Front Brake
SRAM Guide RS, hydraulic disc, organic pads, Guide S4 4-piston caliper
Rear Brake
SRAM Guide RS, hydraulic disc, organic pads, Guide S4 4-piston caliper
Suspension
Rear Shock
Custom RockShox Micro Brain shock w/ Spike Valve, AUTOSAG, 51x257mm
Fork
FOX Performance Step-Cast 34, Grip damper, Boost™, 44mm offset, 120mm of travel
WHEELS
Rims
Roval Control Carbon, 25mm internal width, tubeless-ready
Front Hub
Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub
DT Swiss 370, SRAM XD 3-pawl driver body, 12mm thru-axle, 148mm spacing, 28h
Spokes
DT Swiss Industry
Front Tire
Ground Control, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
Rear Tire
Fast Trak, GRID casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
Inner Tubes
Presta, 60mm valve
COCKPIT
Handlebars
Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
SeatPost
X-Fusion manic, 30.9mm, (S: 100mm, M-XL: 125mm)
Stem
Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Tape
Specialized Trail Grips
Saddle
Body Geometry Power Sport, steel rails
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Crank Length | 170mm | 175mm | 175mm | 175mm |
| Handlebar Width | 750mm | 750mm | 750mm | 750mm |
| Stem Length | 60mm | 70mm | 70mm | 80mm |
| Saddle Width | 155mm | 143mm | 143mm | 143mm |
| Seatpost Length | 361mm | 411mm | 411mm | 411mm |
| Stack | 595mm | 605mm | 619mm | 638mm |
| Reach | 398mm | 423mm | 446mm | 465mm |
| Head Tube Length | 95mm | 105mm | 120mm | 140mm |
| Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° |
| BB Height | 340mm | 340mm | 340mm | 340mm |
| BB Drop | 32mm | 32mm | 32mm | 32mm |
| Trail | 99mm | 99mm | 99mm | 99mm |
| Fork Length, Full | 526mm | 526mm | 526mm | 526mm |
| Fork Rake/Offset | 43mm | 43mm | 43mm | 43mm |
| Front Center | 667mm | 695mm | 723mm | 749mm |
| Chainstay Length | 438mm | 438mm | 438mm | 438mm |
| Wheelbase | 1103mm | 1132mm | 1159mm | 1186mm |
| Top Tube Length, Horizontal | 571mm | 599mm | 626mm | 650mm |
| Bike Standover Height | 772mm | 777mm | 782mm | 804mm |
| Seat Tube Length | 400mm | 434mm | 470mm | 520mm |
| Seat Tube Angle | 73.8° | 73.8° | 73.8° | 73.8° |
