When pedal efficiency and downhill-crushing damping are at the top of your list of…
When pedal efficiency and downhill-crushing damping are at the top of your list of priorities, a coil shock provides the best of both worlds. Combine this with Öhlins suspension technologies, plus the all-new Enduro frame, and you're left with a bike that slays both climbs and descents with equal prowess.
We gave it a geometry that features a slacker front end, a longer top tube, short chainstays, and a lower bottom bracket. All of this together makes the bike truly feel glued to the ground, and the platform is more responsive and capable then ever. We even added some bits, like integrated storage with a SWAT™ Door at the down tube, and made "old" new again by making a triumphant return to a threaded bottom bracket. To keep the weight down, the frame is constructed from our top-tier FACT IS-X 11m carbon fiber. And to ensure top-level performance on the descents, this material choice is greeted by 160mm of plush rear and 160mm front travel, plus a geometry that can be "adjusted" via a shock extension with a "low/high" setting.
Handling suspension duties out back is the revolutionary Öhlins twin tube coil shock, making for the perfect combination of pedaling efficiency and downhill-smashing damping that will have you going faster both up, and down. We even made it to be compatible with our 6Fattie Wheel/Tire system (wheels/tires not included), so you'll always be ready for the trail ahead.
As for the build, the Enduro Coil makes no compromises in the performance department, yet leaves you enough for a post-ride beverage. It features a full SRAM GX 11-speed groupset, a Race Face Aeffect crankset, powerful Code R brakes with S4 calipers, stupid-fast Roval wheels, a Command Post IRcc Wu dropper post, and an Öhlins RXF fork. The days of coil suspension appearing only on the bikes of Enduro World Series pros, like Curtis Keene and Jared Graves, are over. There's nothing that can stand in your way.
The frame's FACT IS-X 11m carbon fiber construction stands as the pinnacle of lightweight, efficient, and tough trail performance. It's been built off our 29 Geometry, which also lends itself to running 6Fattie wheels and tires (only a 5mm BB drop), in order to provide an aggressive, well-rounded ride. And with internal Command Post IR routing, a return to a threaded bottom bracket, and an integrated SWAT™ Door at the down tube, you get a bike that's clean, dependable, and ready for anything that the trail has to offer.
Featuring a three-chamber air spring and TTX (Twin Tube) damping, the Öhlins RXF 36 fork perfectly mates stiffness with a plush, responsive ride quality, and stays smooth and high in the travel without compromising bump absorption, traction, or stability. It also features high-/low-speed and rebound adjustments, and sports 160mm of plush travel.
SRAM's 11-speed GX groupset features a wide gear range that delivers climbing and descending efficiency in spades. On top of this, the one-by setup is notorious for being next to impossible to drop a chain with, plus it provides a significant weight savings in comparison to a standard two-by setup.
FRAME
FACT 11m, X-Wing layout, full carbon chassis and rear end, All Mountain Geometry, SWAT™ Door integration, threaded BB, fully enclosed internal cable routing, ManFu link, oversized pivot bearings, alloy link and adjustable shock extension, 12x148mm dropouts, replaceable derailleur hanger, 160mm of travel
SEAT BINDER
Alloy, 38.6mm
REAR SHOCK
Custom Öhlins TTX, Twin-Tube design, high- and low-speed compression adjust, rebound adjust
FORK
Öhlins RXF 36, 29/6Fattie, Twin-Tube design, coil spring, adjustable high and low-speed compression, adjustable rebound, 15x110mm thru-axle, 51mm offset, 160mm of travel
RIMS
Roval Traverse Carbon 29, hookless carbon, 30mm inner width, 24/28h, tubeless ready, hand-built
FRONT HUB
Specialized, sealed cartridge bearings, 15x110mm spacing, 24h
REAR HUB
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES
DT Swiss Revolution
FRONT TIRE
Butcher, GRID Casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
REAR TIRE
Butcher, GRID casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
INNER TUBES
Standard, Presta valve
REAR DERAILLEUR
SRAM GX, long cage, 11-speed
SHIFT LEVERS
SRAM GX, trigger, 11-speed
CASSETTE
SRAM XG 1150, 11-speed, 10-42t
CHAIN
KMC X11, 11-speed w/ Missing Link™
CRANKSET
Race Face Aeffect alloy crank, 24mm spindle, 28t direct mount ring, 6000 series alloy
CHAINRINGS
Steel, 28T
BOTTOM BRACKET
Race Face PF30
STEM
Specialized Trail, 3D-forged alloy, 4-bolt, 6-degree rise
HANDLEBARS
Specialized DH, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 800mm, 31.8mm clamp
GRIPS
Specialized Sip grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Command Post IRcc WU, 12-position micro-height adjustable, alien head design, bottom mount cable routing, remote adjust SRL lever, 34.9mm, 150mm of travel
FRONT BRAKE
SRAM Code R, 4-piston caliper, hydraulic disc, metallic pads, 200mm rotor
REAR BRAKE
SRAM Code R, 4-piston caliper, hydraulic disc, metallic pads, 180mm rotor
PEDALS
Specialized Platform, Cr-Mo, 9/16" spindle
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 170mm | 170mm | 170mm | 170mm |
Handlebar Width | 800mm | 800mm | 800mm | 800mm |
Stem Length | 45mm | 45mm | 45mm | 60mm |
Saddle Width | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 395mm | 420mm | 420mm | 420mm |
Stack | 606mm | 606mm | 619mm | 633mm |
Reach | 415mm | 440mm | 462mm | 483mm |
Head Tube Length | 95mm | 95mm | 110mm | 125mm |
Head Tube Angle | 66° | 66° | 66° | 66° |
Head Tube Angle, Low Setting | 65.5mm | 65.5mm | 65.5mm | 65.5mm |
BB Height | 354mm | 354mm | 354mm | 354mm |
BB Height, Low Setting | 346mm | 346mm | 346mm | 346mm |
BB Drop | 19mm | 19mm | 19mm | 19mm |
Trail | 107mm | 107mm | 107mm | 107mm |
Fork Length, Full | 569mm | 569mm | 569mm | 569mm |
Fork Rake/Offset | 51mm | 51mm | 51mm | 51mm |
Front Center | 732mm | 757mm | 785mm | 812mm |
Chainstay Length | 433mm | 433mm | 433mm | 433mm |
Wheelbase | 1165mm | 1190mm | 1218mm | 1245mm |
Top Tube Length, Horizontal | 559mm | 584mm | 611mm | 637mm |
Bike Standover Height | 763mm | 769mm | 781mm | 799mm |
Seat Tube Length | 396mm | 430mm | 467mm | 521mm |
Seat Tube Angle | 76.7° | 76.7° | 76.5° | 76.3° |
