While the real fun starts where the road ends, you still need a bike that'll get…
While the real fun starts where the road ends, you still need a bike that'll get you there—one bike that shreds flowy singletrack, gravel, and traditional roads with equal authority. A more capable road bike won’t cut it, nor will a more road-worthy 'cross bike for that matter. No, you need a dedicated gravel bike like the Diverge. First and foremost, it's fun and always down for a good time, but with our fast and stable Open Road Geometry and plenty of tire clearance, it redefines the possibilities for adventure on a drop-bar bike.
We wanted to ensure that your new Diverge E5 rides comfortably, shifts crisply, and brakes smoothly for years to come, so you'll find a Shimano Claris 8-speed groupset, hassle-free mechanical disc brakes, our fan-favorite Power Sport Saddle, and a durable Axis Sport Disc wheelset that's been cased in our fast-rolling, 35mm Roadsport tires with built-in flat protection.
The Diverge has everything you need for pretty much any pedal-powered adventure—whether it's gravel racing, bikepacking, or weekend shredding. Our Premium E5 Aluminum frameset features our comfortable and confident Open Road Geometry, making it the ultimate tool for your next ride.
You can think of the Diverge's geometry as a road version of a modern trail bike. It provides playful handling and predictable steering for endless dirt skids and mid-corner drifts, but keeps stiffness up to snuff for your inner-racer. Along with a bottom bracket that's over a half-centimeter lower than the previous Diverge, we also slacked-out the head tube angle, shortened the chainstays, and made a shorter wheelbase. The result? A bike that performs equally well over both the dirt and road.
The full FACT carbon fiber fork keeps overall weight low and takes the sting out of road imperfections with ease.
Handlebars
Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Saddle
Body Geometry Power Sport, hollow Cr-Mo rails
SeatPost
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Tape
Specialized S-Wrap
Seat Binder
Diverge rack-mount seat collar
Shift Levers
Shimano Claris 2000, 8-speed
Front Derailleur
Shimano Claris, 8-speed, braze-on
Rear Derailleur
Shimano Claris, 8-speed
Cassette
SunRace, 8-speed, 11-34t
Crankset
Shimano Claris R200
Chainrings
50/34T
Bottom Bracket
BSA, 68mm, square-taper
Chain
KMC X8 w/ Missing Link™, 8-speed
Front Wheel
Axis Sport Disc
Rear Wheel
Axis Sport Disc
Front Tire
Specialized Roadsport, 60TPI, wire bead, Flak Jacket protection, 700x35mm
Inner Tubes
Presta valve, 48mm
Rear Tire
Specialized Roadsport, 60TPI, wire bead, Flak Jacket protection, 700x35mm
Fork
Specialized FACT carbon, flat-mount disc, 12x100mm thru-axle
Rear Brake
Tektro Mira, flat-mount, mechanical disc
Front Brake
Tektro Mira, flat-mount, mechanical disc
Pedals
REMOVE
SWAT
Fender Clamp Adaptor
Frame
Specialized E5 Premium Aluminum, Open Road Geometry, threaded BB, 12x142mm thru-axle, flat-mount disc
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
44.0 | 48.0 | 52.0 | 54.0 | 56.0 | 58.0 | 61.0 | |
---|---|---|---|---|---|---|---|
Crank Length | 165mm | 165mm | 170mm | 170mm | 175mm | 175mm | 175mm |
Stem Length | 70mm | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
Handlebar Width | 360mm | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
Seatpost Length | 350mm | 350mm | 350mm | 400mm | 400mm | 400mm | 400mm |
Saddle Width | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Stack | 553mm | 554mm | 560mm | 577mm | 598mm | 624mm | 647mm |
Reach | 357mm | 365mm | 372mm | 378mm | 384mm | 390mm | 397mm |
Head Tube Length | 125mm | 125mm | 130mm | 143mm | 163mm | 190mm | 213mm |
Head Tube Angle | 70.5° | 70.8° | 71° | 71.9° | 72.5° | 72.5° | 72.8° |
BB Height | 265mm | 265mm | 265mm | 265mm | 265mm | 265mm | 265mm |
BB Drop | 85mm | 85mm | 85mm | 85mm | 85mm | 85mm | 85mm |
Trail | 66mm | 64mm | 62mm | 62mm | 58mm | 58mm | 56mm |
Fork Length, Full | 390mm | 390mm | 390mm | 390mm | 390mm | 390mm | 390mm |
Fork Rake/Offset | 55mm | 55mm | 55mm | 50mm | 50mm | 50mm | 50mm |
Front Center | 587mm | 593mm | 600mm | 598mm | 604mm | 618mm | 629mm |
Chainstay Length | 422mm | 422mm | 422mm | 424mm | 424mm | 424mm | 424mm |
Wheelbase | 994mm | 1000mm | 1007mm | 1007mm | 1014mm | 1028mm | 1039mm |
Top Tube Length, Horizontal | 516mm | 524mm | 532mm | 549mm | 561mm | 575mm | 589mm |
Bike Standover Height | 691mm | 712mm | 734mm | 761mm | 783mm | 810mm | 837mm |
Seat Tube Length | 370mm | 405mm | 440mm | 473mm | 500mm | 525mm | 555mm |
Seat Tube Angle | 74° | 74° | 74° | 73.5° | 73.5° | 73.5° | 73.5° |
