2009 Demo 8
0 Reviews
BUILT FOR STEEP TRAILS AND BIG AIR, our Demo laughs in the face of ruthless terrain…
Product Details
BUILT FOR STEEP TRAILS AND BIG AIR, our Demo laughs in the face of ruthless terrain with 7 and 8 inches of generous travel. Its top-of-the line Fox components, stable geometry with low central mass and insanely strong double ORE down tubes are competition-proven to withstand the most extreme abuse.
Custom Avid Elixir R brakes feature full hydraulic calipers, metallic pads and a big 203mm rotor in front and 185mm in back for awesome control in fast and steep situations. Elixir R levers have a tool-free reach adjustment feature for enhanced comfort an
32-hole DT Swiss F550 rims are custom for Specialized. 32mm width, eyelets and a sleeved joint bump up durability. DT Swisss Champion stainless spokes provide a true build and long-haul durability.
Specialized Hi-Lo hub features variable sized flanges for a perfectly tensioned, ultra durable wheel. A 20mm thru-axle on the front improves stiffness and steering precision, while the 10mm chromoly axle in back increases durability.
8.2-inch travel M5 manipulated alloy frame features a cold-forged head tube, seat tube, bottom bracket shell, linkage points and center rib cage for off-the-charts durability. Adjustable geometry for situation-specific tuning.
World-beating Boxxer Race fork with 203mm of plush, coil-sprung travel. Motion Control damping and external compression and rebound adjust help riders dial in performance for any course.
Technical Specifications
FRAMESET
FRAME
Demo 8 FSR M5 Manipulated Alloy, 8.2"" travel, asymetrical rear triangle, ISCG mount, adj. geometry, 1-1/8"" forged HT, cartridge bearing rear shock mount, rear derailleur protector
HEADSET
1-1/8"" Threadless, 13mm insertion alloy cups with OS lower cartridge and bearing
SEAT BINDER
7050 hard annodized alloy collar w/ QR, 34.9mm clamp ID, black
SUSPENSION
REAR SHOCK
Fox DHX 4.0 coil 8.75x2.75"", ProPedal and rebound adj., bottom out control and IFP pressure, S:450, M:500, L:550
FORK
RockShox Boxxer Race, 203mm travel, motion control damper, alloy steerer, external compression and rebound adj., 20mm maxle DH thru-axle
WHEELS
FRONT TIRE
Specialized Chunder SX 26x2.3"", 60 TPI, aramid bead, cap ply, soft dual compound
REAR TIRE
Specialized Chunder SX 26x2.3"", 60 TPI, aramid bead, cap ply, soft dual compound
INNER TUBES
Specialized 26x2.3"", presta
RIMS
Custom DT Swiss F550, 30mm, 32h
FRONT HUB
Specialized Hi-Lo disc, 20mm thru-axle, 32h
REAR HUB
Specialized thru axle 135mm, hollow 10mm Cr-Mo axle w/ RD guard
SPOKES
DT Swiss Champion 2.0mm stainless, brass nipples
DRIVETRAIN
REAR DERAILLEUR
SRAM X-9, 9-speed, short cage
SHIFT LEVERS
SRAM X-7, trigger, 9-speed
CASSETTE
SRAM PG-970, 12-26t
CHAIN
SRAM PC-971, 9-speed w/Power Link
CRANKSET
Truvativ Hussefelt, 170mm w/ Gamut P-30 chain guide
BOTTOM BRACKET
Truvativ Howitzer XR, oversize sealed outboard cartridge bearing, 73mm shell
COCKPIT
STEM
Specialized Aggro stem, 35mm extension, OS 31.8, 4-bolt, forged
HANDLEBARS
Specialized Demo rise bar, 6066 alloy, 31.8mm, 6 degree up, 9 degree backsweep, 680mm wide
GRIPS
Specialized lock on grip, alloy bar ends
SADDLE
Specialized Enduro, 8mm hollow Cr-Mo rails, SL foam
SEATPOST
6061 butted alloy, two bolt setback, 30.9x300mm
BRAKES
FRONT BRAKE
Custom Avid Elixir R hydraulic disc, reach adjust, metallic pads, 203mm rotor
REAR BRAKE
Custom Avid Elixir R, hydraulic disc, reach adjust, metallic pads, 185mm rotor
BRAKE LEVERS
Custom Avid Elixir R Hydraulic, tool-less adj. reach
ACCESSORIES
PEDALS
Specialized Lo-Pro alloy
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | |
|---|---|---|---|
| Bottom Bracket Height - Low Setting | 368mm | 368mm | 368mm |
| Top Tube Length (Horizontal) | 550mm | 575mm | 592mm |
| Head Tube Height | 120mm | 120mm | 120mm |
| Head Tube Angle - Low Setting | 64° | 64° | 64° |
| Seat Tube Angle (Actual) - Low Setting | 64.5° | 64.5° | 64.5° |
| Seat Tube Angle (Effective) - Low Setting | 75° | 75° | 75° |
| Top Tube Length (Actual) | 520mm | 540mm | 554mm |
| Head Tube Angle - High Setting | 65° | 65° | 65° |
| Bottom Bracket Height - High Setting | 380mm | 380mm | 380mm |
| Seat Tube Angle (Actual) - High Setting | 65.5° | 65.5° | 65.5° |
| Seat Tube Angle (Effective) - High Setting | 76° | 76° | 76° |
| Seat Tube Length - Center to Top | 432mm | 432mm | 457mm |
| Wheel Base | 1168mm | 1196mm | 1213mm |
| Standover Height | 754mm | 759mm | 769mm |
| Chainstay Length | 421mm | 421mm | 421mm |
| Crank Length | 170mm | 170mm | 170mm |
| Handlebar Width | 680mm | 680mm | 680mm |
| Stem Length | 35mm | 35mm | 35mm |
| Seatpost Length | 367mm | 367mm | 367mm |
