2014 Crossroads Step Through
0 Reviews
Blaze the bike path, explore the outdoors! Fun and fast, forgiving and stable, the…
Product Details
Blaze the bike path, explore the outdoors! Fun and fast, forgiving and stable, the Crossroads Step Through, with 21-speeds and fast but wide tires, is the perfect tool to get out there and test boundaries—both yours and the neighborhood's.
A1 Premium Aluminum frame with custom geometry for quick and correct fit to size, includes integrated kickstand mount
Lightweight, rigid steel fork delivers improved handling, plus rack/fender mounts for added utility
Smooth-rolling and super-tough Borough tires can comfortably handle any terrain
Body Geometry Comfort closed-end grips for an ergonomic contact point to keep hands fatigue-free
Body Geometry Comfort saddle has dual-density foam to give the most comfortable ride, but still allows for full range of motion on the bike
Technical Specifications
FRAMESET
FRAME
A1 Premium Aluminum, custom formed tubes, forged dropouts w/ replaceable derailleur hanger
FORK
Specialized steel, custom profile
HEADSET
1-1/8"" FSA Intelaset, threaded, Cr-Mo cups
SEAT BINDER
Alloy, QR
WHEELS
RIMS
Alloy double-wall, CNC sidewalls, 32h
FRONT HUB
Double-sealed, ground race, dual-lock nuts w/ 17mm contact side, 5mm QR
REAR HUB
Freewheel type, nutted
SPOKES
Stainless, 14g (2.0mm)
FRONT TIRE
Specialized Borough, 60TPI, wire bead, 700x45c
REAR TIRE
Specialized Borough, 60TPI, wire bead, 700x45c
INNER TUBES
Standard Schrader valve
DRIVETRAIN
SHIFT LEVERS
Shimano, 7-Speed, Revo-shift
FRONT DERAILLEUR
Shimano, top-swing, dual-pull
REAR DERAILLEUR
Shimano, 7-speed
CASSETTE
Shimano MegaRange, 7-speed, 14-34
CRANKSET
Forged crank arm w/ press on ring, w/ chainguard
CHAINRINGS
48/38/28
BOTTOM BRACKET
Cartridge bearings, square spindle, capless bolts
CHAIN
KMC Z7
COCKPIT
HANDLEBARS
Specialized riser bar, alloy, 8-degree backsweep, 60mm rise, 25.4mm
STEM
Adjustable quill, die-cast alloy, 2-bolt, 150mm x 25.4mm clamp
TAPE
Specialized Body Geometry Comfort, dual compound
SADDLE
Specialized Body Geometry Comfort Women's, 200mm
SEATPOST
Alloy, 2-bolt, 12.5mm offset, 27.2mm
BRAKES
FRONT BRAKE
Die-cast, alloy V-brake, 60mm 1pc. pad, linear pull
REAR BRAKE
Die-cast, alloy V-brake, 60mm 1pc. pad, linear pull
BRAKE LEVERS
Alloy, four-finger lever
ACCESSORIES
PEDALS
Plastic, sealed loose ball bearings, w/ reflectors
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| XS | SM | MD | LG | |
|---|---|---|---|---|
| Seat-Tube Angle | 71° | 71° | 71° | 71° |
| Head-Tube Length | 135mm | 145mm | 175mm | 190mm |
| Seat-Post Length | 300mm | 350mm | 350mm | 350mm |
| Head-Tube Angle | 69° | 69.5° | 70.5° | 70.5° |
| Chain-Stay Length | 465mm | 465mm | 465mm | 465mm |
| Top-Tube Length, Horizontal | 555mm | 570mm | 585mm | 600mm |
| Front-Center | 615mm | 624mm | 625mm | 641mm |
| Handle-Bar Width | 660mm | 660mm | 660mm | 660mm |
| Stand-Over Height | 650mm | 665mm | 694mm | 711mm |
| Seat-Tube Length, B-B Center to Top | 370mm | 425mm | 485mm | 535mm |
| Fork Rake | 55mm | 55mm | 51mm | 51mm |
| B-B Drop | 65mm | 65mm | 65mm | 65mm |
| Trail | 74mm | 72mm | 72mm | 72mm |
| Wheelbase | 1072mm | 1081mm | 1082mm | 1098mm |
| Crank Length | 170mm | 170mm | 175mm | 175mm |
| Stem Length | 50mm | 50mm | 50mm | 50mm |
