2015 Allez Pro
0 Reviews
The Allez Pro features a D'Aluisio Smartweld frame with hydroformed tubesets, OSBB,…
Product Details
The Allez Pro features a D'Aluisio Smartweld frame with hydroformed tubesets, OSBB, and full monocoque carbon fork. You'll make easy work of the toughest climbs, steepest descents, and lead the fastest group rides.
Fulcrum S3 blend lightweight performance with all-day durability to keep you rolling
Specialized E5 aluminum frame w/ D'Aluisio Smartweld Technology is light and fast
Specialized Turbo Pro 700x25c tires offer equal parts performance and cornering grip
SRAM Force 22 crankset is equal parts lightweight and stiff thanks to the BB30 design
SRAM RED 22 rear derailleur for 11-speed performance across the entire gear ratio
Body Geometry Toupé Expert Gel saddle w/ hollow Cr-Mo rails is tuned for perfect fit and comfort
Specialized FACT carbon, full monocoque fork designed for high-speed handling
The custom color—Rocket Red—is designed to naturally age over time. It will exhibit splashes of a dark rich color when exposed to prolonged direct sunlight. This finish is deliberate and therefore not covered under the traditional warranty policy.
Technical Specifications
FRAMESET
FRAME
Specialized E5 Premium Aluminum w/ D'Aluisio Smartweld Technology, hydroformed aluminum tubing, tapered headtube, OSBB
FORK
Specialized FACT carbon, full monocoque, 1-3/8"" lower bearing
HEADSET
1-1/8"" upper, 1-3/8” lower, steel bearings, 8mm alloy cone spacer, w/ 20mm spacers
SEAT BINDER
Alloy, 31.2mm
WHEELS
FRONT WHEEL
Fulcrum S3
REAR WHEEL
Fulcrum S3
FRONT TIRE
Specialized Turbo Pro, 127TPI, folding bead, BlackBelt protection, 700x25c
REAR TIRE
Specialized Turbo Pro, 127TPI, folding bead, BlackBelt protection, 700x25c
INNER TUBES
Ultralight, presta valve
DRIVETRAIN
FRONT DERAILLEUR
SRAM Force 22, YAW, w/ chain spotter
REAR DERAILLEUR
SRAM RED 22
SHIFT LEVERS
SRAM RED 22, 11-speed
CASSETTE
SRAM PG 1170, 11-speed, 11-28
CHAIN
SRAM PC 1170, 11-speed
CRANKSET
SRAM Force 22, BB30, 52/36
BOTTOM BRACKET
SRAM, BB30
COCKPIT
STEM
Specialized Pro SL, alloy, 4-bolt
HANDLEBARS
Specialized Expert, shallow drop, alloy, 123mm drop, 75mm reach
TAPE
Specialized S-Wrap, w/ bar end plug, 8mm bar shaper
SADDLE
Body Geometry Toupé Expert Gel, hollow Ti rails, 143mm
SEATPOST
S-Works FACT carbon, 20mm offset, 27.2mm
BRAKES
FRONT BRAKE
SRAM Force
REAR BRAKE
SRAM Force
BRAKE LEVERS
SRAM Red 22
ACCESSORIES
PEDALS
Nylon flat test ride, loose-ball, w/ reflectors
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Seat-Tube Angle | 75.5° | 74° | 73.5° | 73.25° | 73° | 72.5° |
| Head-Tube Length | 120mm | 120mm | 145mm | 170mm | 205mm | 230mm |
| Seat-Post Length | 300mm | 300mm | 350mm | 350mm | 350mm | 350mm |
| Head-Tube Angle | 72.25° | 73° | 73° | 73.5° | 73.5° | 74° |
| Chain-Stay Length | 405mm | 405mm | 405mm | 405mm | 407mm | 410mm |
| Top-Tube Length, Horizontal | 518mm | 537mm | 548mm | 565mm | 582mm | 600mm |
| Front-Center | 576mm | 576mm | 583mm | 591mm | 605mm | 613mm |
| Handle-Bar Width | 400mm | 420mm | 420mm | 420mm | 440mm | 440mm |
| Stand-Over Height | 741mm | 777mm | 798mm | 816mm | 836mm | 854mm |
| Seat-Tube Length, B-B Center to Top | 460mm | 480mm | 500mm | 520mm | 540mm | 580mm |
| Fork Rake | 45mm | 45mm | 45mm | 43mm | 43mm | 43mm |
| B-B Drop | 71.5mm | 71.5mm | 69mm | 69mm | 67.5mm | 67.5mm |
| Stack | 523mm | 523mm | 547mm | 574mm | 606mm | 631mm |
| Reach | 380mm | 385mm | 387mm | 395mm | 402mm | 408mm |
| Trail | 62mm | 57mm | 57mm | 56mm | 56mm | 53mm |
| Wheelbase | 970mm | 970mm | 978mm | 986mm | 1003mm | 1013mm |
| Crank Length | 170mm | 170mm | 173mm | 173mm | 175mm | 175mm |
| Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
