When we developed the new Women's S-Works Tarmac Disc, we didn't just want it to…
When we developed the new Women's S-Works Tarmac Disc, we didn't just want it to be fast. No, we wanted it to be fast everywhere. Long climbs, windy flats, Grand Tour stages, local fondos—we built a women's race bike to be the most complete out there. And now with disc brakes, we've managed to make it, well, even more complete.
For the construction, we utilized advanced aerospace composite optimization software to revolutionize the construction and layup of our new FACT 12r carbon. It's the most advanced material, and schedule, we've ever made and this allowed us to shed nearly 200 grams. That's right, a 20% reduction in frame weight—the perfect recipe for your next hill climb PR.
We also took major steps to improving our Rider-First Engineered™ technology to ensure that the new Tarmac is stiff and compliant in exactly the right places, all while shedding some serious weight. From different layup schedules and materials, to visibly different forks, we scrutinized every single aspect of the new Tarmac to ensure you're getting the perfect ride. With this revamp, we also updated the geometry, basing it on countless Retül data points and professional rider input. This enabled us to develop a Performance Road Geometry that perfects the combination of a responsive front-end and short wheelbase, which delivers instantaneous response and optimal power transfer.
And while stiffness aids in the aforementioned, compliance must also be utilized for an optimal ride quality. That's why we designed a seatpost that builds compliance into the upper 120mm where clamping doesn't happen, dropped the seatstays, and altered the seat tube shape. We also added tire clearance up to 30mm, which translates to a 28mm Turbo Cotton on a Roval CLX 50 Disc wheel. This allows lower pressures for decreased rolling resistance, increased traction, and more comfort. Altogether, these additions still have the Tarmac riding like a true race-machine, but it also takes a bit of the sting out of road imperfections. You'll thank us on your next long ride. But why disc brakes? The real question is "why not?" They offer superior braking power and modulation, work exceptionally well in wet weather, and offer a very, very minor weight addition. All this means that you have more control and can go faster with more confidence.
We also know, however, that aerodynamic improvements are the most important thing we can do to make you faster. Our Boels-Dolmans Pro Tour riders, after all, are demanding aero improvements on every bike. With this, the aero goal was to discover where we could essentially "add aero for free," by not taking anything away from the hallmarks of the Women's Tarmac design. During the six-month iterative process, three areas were discovered where we could do this—a new fork shape, dropped seatstays with aero tubes, and a D-shaped seatpost and seat tube. The result? A bike that's approximately 45 seconds faster over 40km compared to other lightweight bikes in the same category.
Next, we included the lightest (440g/172.5mm) and most accurate power meter available, because no matter your skill level or experience on the bike, there's no better way to enhance your training and racing performance than by riding with a power meter. Lucky for you, we've combined our incredibly light and stiff carbon fiber S-Works road cranks with dual-sided power measurement.
This S-Works Tarmac comes ready to race with Shimano's new Dura-Ace 9170 Di2 groupset with disc brakes, light and aero Roval CLX 50 Disc wheels with 26mm Turbo Cotton tires, and a host of women's-specific pieces at every touchpoint on the bike, like a superlative Oura Pro saddle.
Featuring our Rider-First Engineered™ design that ensures every frame size has the same legendary climbing responsiveness and descending prowess you'd expect from a Tarmac. The S-Works FACT 12r frame is our highest quality carbon frame, offering the ideal blend of light overall weight and targeted stiffness.
Shimano's Dura-Ace Di2 group offers exceptionally crisp shifts, smooth braking modulation, and it keeps the overall weight of the Tarmac at an absolute minimum.
The Win Tunnel Engineered Roval CLX 50 Disc carbon wheelset provides superior aerodynamics, a svelte 1415-gram weight, and plenty of durability to be both a perfect training and race wheelset.
FRAME
FACT 12r carbon fiber, Rider-First Engineered™, OSBB, clean routing, internally integrated seat clamp, 12x142mm thru-axle, flat-mount disc
HANDLEBARS
S-Works Shallow Bend Carbon, 125mm drop x 75 mm reach
STEM
S-Works SL, alloy, titanium bolts, 6-degree rise
TAPE
S-Wrap Roubaix w/ sticky gel
SADDLE
Oura Pro, 155mm, carbon rails, carbon base
SEATPOST
S-Works FACT carbon Tarmac seatpost, 20mm offset
SEAT BINDER
Tarmac SL6 clamp assembly
REAR BRAKE
Shimano Dura-Ace R9170, hydraulic disc
FRONT BRAKE
Shimano Dura-Ace R9170, hydraulic disc
SHIFT LEVERS
Shimano Dura-Ace Di2 Disc R9170
FRONT DERAILLEUR
Shimano Dura-Ace Di2 R9150, braze-on
REAR DERAILLEUR
Shimano Dura-Ace Di2 R9150
CASSETTE
Shimano Dura-Ace R9100, 11-speed, 11-30t
CRANKSET
S-Works Power Cranks, dual-sided power measurement, +/- 1.5% accuracy
CHAINRINGS
52/36T
BOTTOM BRACKET
OSBB, CeramicSpeed bearings
CHAIN
Shimano Dura-Ace, 11-speed
FRONT WHEEL
Roval CLX 50 Disc, carbon, tubeless-ready, Win Tunnel Engineered, 50mm depth, CeramicSpeed bearings, 21h
REAR WHEEL
Roval CLX 50 Disc, carbon, tubeless-ready, Win Tunnel Engineered, 50mm depth, DT Swiss 240 internals, CeramicSpeed bearings, 24h
FRONT TIRE
Turbo Cotton, 320 TPI, 700x26mm
REAR TIRE
Turbo Cotton, 320 TPI, 700x26mm
INNER TUBES
Turbo Ultralight, 60mm Presta valve
FORK
S-Works FACT carbon, 12x100mm thru-axle, flat-mount disc
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
44 | 49 | 52 | 54 | 56 | |
---|---|---|---|---|---|
Crank Length | 165mm | 167.5mm | 170mm | 170mm | 172.5mm |
Handlebar Width | 360mm | 380mm | 400mm | 400mm | 420mm |
Stem Length | 70mm | 80mm | 90mm | 100mm | 100mm |
Saddle Width | 155mm | 155mm | 155mm | 155mm | 155mm |
Seatpost Length | 320mm | 320mm | 320mm | 380mm | 380mm |
Stack | 500mm | 514mm | 527mm | 544mm | 565mm |
Reach | 365mm | 375mm | 380mm | 384mm | 395mm |
Head Tube Length | 105mm | 115mm | 126mm | 143mm | 163mm |
Head Tube Angle | 70.5° | 71.75° | 72.5° | 73° | 73.5° |
BB Height | 266mm | 266mm | 266mm | 268mm | 268mm |
BB Drop | 74mm | 74mm | 74mm | 72mm | 72mm |
Trail | 71mm | 63mm | 58mm | 58mm | 55mm |
Fork Length, Full | 363mm | 363mm | 363mm | 363mm | 363mm |
Fork Rake/Offset | 47mm | 47mm | 47mm | 44mm | 44mm |
Front Centre | 571mm | 574mm | 577mm | 579mm | 591mm |
Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm |
Wheelbase | 969mm | 973mm | 975mm | 978mm | 990mm |
Top Tube Length, Horizontal | 490mm | 508mm | 531mm | 540mm | 562mm |
Bike Standover Height | 730mm | 740mm | 755mm | 775mm | 795mm |
Seat Tube Length | 400mm | 431mm | 462mm | 481mm | 501mm |
Seat Tube Angle | 76° | 75.5° | 74° | 74° | 73.5° |
