Experience � Comfort Street Whatever it is that makes people head to their bikes,…
Colour:
All Colors 2
Experience � Comfort Street Whatever it is that makes people head to their bikes, whether it�s pleasure, fitness, or efficient transportation, for many riders there is often a common desire for comfort to be an integral part of every ride. A great ride is often little more than a ride that�s comfortable, enjoyable, and leaves one looking forward to the next opportunity to get out and ride: plain and simple, fun and relaxing. Whether it�s commuting across the city, along the local bike path, or out to a favourite beachfront lunch spot, a Crossroads will get you there and back again � easily, comfortably, and reliably.
Ergonomically designed lightweight A1 Premium Aluminium anatomic frame with a Specialized 63mm travel fork with pre-load
Superior Shimano Nexave/Alivio 8-speed shifting with 11-32 Mega Range drive train and EZ Fire shifting
Enhanced comfort features include Body Geometry Sport saddle, plush alloy suspension seatpost and soft Body Geometry Comfort triple-density grips
Alex DH-19 double wall alloy rims combined with double sealed Specialized/Shimano hubs
New Specialized 700x38c Crossroads tyres with Flak Jacket puncture protection technology
FRAME
Specialized Street, A1 Premium Aluminum, heat treated
FORK
Specialized TCR-043D, 63mm travel w/preload
HEADSET
Specialized 1 1/8"" threaded, loose ball
SEAT BINDER
Specialized forged alloy w/AH binder
RIMS
Alex DH-19,700x28c, alloy double wall, w/machine sidewalls
FRONT HUB
Specialized forged, 32 hole, double sealed, QR
REAR HUB
Shimano Paralax, forged, 32 hole, cassette, double sealed, QR
SPOKES
Specialized, 2.0mm (14g), stainless, brass nipples, L294/R294mm front, L293/R291mm rear
REAR DERAILLEUR
Shimano New Alivio, long cage
SHIFT LEVERS
Shimano EF-50 EZ Fire 8 speed shifter
CHAIN
Shimano HG-53 8 speed
CRANKSET
Shimano Nexave 201, silver arms
CHAINRINGS
48Sx38Sx28S, Hyperglide, w/chainguard
BOTTOM BRACKET
Shimano BB-UN-26, 68mm shell, 113 spindle, sealed bearing cartridge
FRONT DERAILLEUR
Shimano Nexave, 31.8 clamp, bottom pull
STEM
Specialized Alloy 25 degree rise
HANDLEBARS
Specialized alloy, 30mm rise, 14 deg sweep
SADDLE
Specialized BG Sport
FRONT BRAKE
Specialized linear pull, forged, w/modulator
REAR BRAKE
Specialized linear pull, forged, w/modulator
BRAKE LEVERS
Shimano EF-50 Integrated
PEDALS
Specialized platform nylon with krypton top
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
XS | S | M | L | XL | WS | WM | |
---|---|---|---|---|---|---|---|
Top Tube Length (Horizontal) | 526mm | 544mm | 560mm | 573mm | 598mm | 533mm | 561mm |
Rake | 50mm | 50mm | 50mm | 50mm | 50mm | 50mm | 50mm |
Seat Tube Length, Center to Center | 330mm | 395mm | 430mm | 465mm | 515mm | 220mm | 260mm |
Seat Tube Length, Center to Top | 375mm | 440mm | 475mm | 510mm | 560mm | 410mm | 490mm |
Bottom Bracket Drop | 68mm | 68mm | 65mm | 65mm | 65mm | 68mm | 65mm |
Wheel Base | 1061mm | 1061mm | 1062mm | 1066mm | 1080mm | 1061mm | 1063mm |
Standover Height | 708mm | 748mm | 776mm | 808mm | 844mm | 663mm | 698mm |
Head Tube Length | 95mm | 110mm | 130mm | 160mm | 190mm | 105mm | 130mm |
Head Tube Angle | 69.5° | 71° | 72° | 72.5° | 72.5° | 70° | 72° |
Trail | 76mm | 66mm | 60mm | 56mm | 56mm | 72mm | 60mm |
Front Center | 615mm | 615mm | 615mm | 619mm | 633mm | 615mm | 616mm |
Chainstay Length | 455mm | 455mm | 455mm | 455mm | 455mm | 455mm | 455mm |
Seat Tube Angle | 76° | 75° | 74° | 73.5° | 72.5° | 75.5° | 74° |
Crank Length | 170mm | 170mm | 175mm | 175mm | 175mm | 170mm | 170mm |
Handlebar Width | 620mm | 620mm | 620mm | 620mm | 620mm | 620mm | 620mm |
Stem Length | 100mm | 100mm | 110mm | 120mm | 120mm | 100mm | 110mm |
Seatpost Length | 350mm | 350mm | 350mm | 350mm | 350mm | 350mm | 350mm |
For safety warning please refer to the documentation in the Manual Downloads section of this page.
