2012 Langster Pro Frameset
0 Reviews
The flat-out fastest—and definitely the sexiest—bike on the track, the new Langster…
Colour:
Flo Red/White
What's my size?
Select a Size
Product Details
The flat-out fastest—and definitely the sexiest—bike on the track, the new Langster Pro features E5 alloy aero tubing for raw, wind-cheating power on the track or an occasional training ride on the open road, build up the frameset with the spec of your choice
A1 Premium Aluminum compact frame with integrated headset, fully manipulated tubing, and track geo excels (and looks awesome) in the city or at the velodrome
Ultralight FACT carbon fork provides precise steering with a classic look
Aero FACT carbon seatpost is reversible for a -10mm or +10mm offset to put you in the optimal power position
Technical Specifications
FRAMESET
FRAME
Specialized A1 Premium Aluminum, fully manipulated aero-shaped tubing, compact design w/ track geo, integrated headset
FORK
Specialized FACT carbon legs, aluminum crown and steerer
HEADSET
1-1/8"" sealed Cr-Mo cartridge bearings integrated w/ headset, 20mm alloy cone spacer, w/ 20mm of spacers
SEAT BINDER
Venge seat clamp assembly
DRIVETRAIN
BOTTOM BRACKET
Cr-Mo axle, 68mm x 103mm
COCKPIT
SEATPOST
Venge Aero, FACT carbon, flippable 20/0mm offset
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 46.0 | 49.0 | 52.0 | 54.0 | 56.0 | 58.0 | 61.0 | |
|---|---|---|---|---|---|---|---|
| Seat-Tube Angle | 74° | 74° | 74° | 74° | 74° | 74° | 74° |
| Head-Tube Length | 95mm | 100mm | 115mm | 130mm | 150mm | 170mm | 190mm |
| Seat-Post Length | 300mm | 300mm | 300mm | 300mm | 350mm | 350mm | 350mm |
| Head-Tube Angle | 71° | 72° | 73° | 73° | 74° | 74° | 74° |
| Chain-Stay Length | 385mm | 385mm | 385mm | 385mm | 385mm | 385mm | 385mm |
| Top-Tube Length, Horizontal | 501mm | 512mm | 529mm | 539mm | 558mm | 569mm | 585mm |
| Front-Centre | 565mm | 568mm | 569mm | 580mm | 584mm | 596mm | 612mm |
| Stand-Over Height | 715mm | 742mm | 760mm | 774mm | 800mm | 819mm | 838mm |
| Seat-Tube Length, B-B Centre to Top | 450mm | 500mm | 515mm | 530mm | 555mm | 575mm | 590mm |
| Fork Rake | 52mm | 50mm | 43mm | 43mm | 37mm | 37mm | 37mm |
| B-B Drop | 55mm | 55mm | 52.5mm | 52.5mm | 50mm | 50mm | 47.5mm |
| Stack | 478mm | 487mm | 504mm | 518mm | 540mm | 559mm | 576mm |
| Reach | 362mm | 372mm | 384mm | 390mm | 403mm | 409mm | 420mm |
| Trail | 63mm | 59mm | 58mm | 58mm | 58mm | 58mm | 58mm |
| Wheelbase | 944mm | 946mm | 948mm | 959mm | 964mm | 975mm | 992mm |
Manual Downloads
For safety warning please refer to the documentation in the Manual Downloads section of this page.
