2020 Allez Sprint Disc Frameset

$1,800.00

4.5

2 Reviews

Climbs, corners, flat-out sprints—the Allez Sprint does it all. Being the most advanced…

Product Details

Add Icon

Climbs, corners, flat-out sprints—the Allez Sprint does it all. Being the most advanced alloy road bike we've ever made, and one that often out-performs the carbon fiber bikes of other brands, the Allez Sprint is capable as a crit-racing tool or an everyday road steed. But even better, it performs all of the above at a price that's affordable for any racer's budget.

This Allez Sprint Disc frameset comes equipped with a Tarmac SL6 FACT carbon fiber fork and a Venge Aero seatpost that's also made from FACT carbon.

  • At the heart of the Allez Sprint is our D'Aluisio Smartweld Technology, which strategically places more welding material where it's needed, resulting in an aluminum bike that's more compliant and considerably stiffer. How stiff, exactly? It's the stiffest alloy bike we've ever tested, let alone made. Drawing inspiration from the Rider-First Engineered™ Tarmac, this frame also has a unique down tube, bottom bracket shell, and head tube, plus fork sizes that correspond to frame size. This ensures uniform performance across the entire size run.

  • To make sure that every single watt you produce gets transferred to the road, we gave it short chainstays that create an extremely stiff and rigid rear triangle. But it goes beyond just pure rigidity, as the hydroformed tube shapes have also been aerodynamically optimized to slice through the wind, while also providing tons of built-in compliance.

  • Drawing inspiration from the Rider-First Engineered™ Tarmac, this frame also has a unique down tube, bottom bracket shell, and head tube, plus fork sizes that correspond to frame size. This ensures uniform performance across the entire size run.

  • Our top-tier Tarmac Disc FACT carbon fiber fork provides incredible stiffness and front-end steering response, while also efficiently absorbing road chatter.

Technical Specifications

Add Icon

Suspension

Fork

Specialized FACT carbon, 1-1/8" to 1-3/8" taper, fender eyelets

FRAMESET

Frame

Specialized E5 Premium Aluminum Disc frame w/ D'Aluisio Smartweld Sprint Technology, hydroformed aluminum tubing, tapered head tube, OSBB

COCKPIT

SeatPost

Allez Sprint Seatpost, 20mm setback

Seat Binder

Allez Sprint Aero

DRIVETRAIN

Bottom Bracket

OSBB, Praxis bearings

* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

Add Icon
49.052.054.056.058.061.0
Seatpost Length330mm330mm330mm330mm330mm330mm
Stack507mm519mm538mm559mm588mm609mm
Reach375mm380mm385mm395mm400mm405mm
Head Tube Length110mm120mm140mm160mm190mm210mm
Head Tube Angle72.25°73°73°73.5°73.5°74°
BB Height271mm271mm271mm271mm271mm271mm
BB Drop69mm69mm69mm69mm69mm69mm
Trail63mm58mm58mm55mm55mm52mm
Fork Length, Full363mm363mm363mm363mm363mm363mm
Fork Rake/Offset44mm44mm44mm44mm44mm44mm
Front Centre566mm568mm579mm590mm603mm609mm
Chainstay Length410mm410mm410mm410mm410mm410mm
Wheelbase966mm968mm979mm990mm1004mm1010mm
Top Tube Length, Horizontal520mm529mm539mm555mm569mm580mm
Bike Standover Height730mm744mm764mm780mm807mm832mm
Seat Tube Length460mm480mm500mm520mm540mm570mm
Seat Tube Angle74°74°74°74°74°74°
Geometry

Rider Reviews

4.5

2 Reviews



OMG !!!

Have just ridden it three times since getting it built up with SRAM Force Axis w hydro disc. LOOOOOVE it!!!! It handles like a dream and climbs like a spider monkey. May be my favorite bike and I've got a S-works tarmac and a Titanium bike as well. It really suprised me as an aluminium frame. For the money, you CANNOT beat it!!


Name:
Fire J.

Helpful?

Frameset

I have yet to build up the frame but it looks fantastic. I do have a question though, is the lower race for the headset built into the fork? I have given the frame 4 stars not 5 because I have yet to ride it.


Name:
Lazybaker

Helpful?
